Cube Ice Makers LCIM-B11

Share :

Cube Ice Makers LCIM-B11

Cube Ice maker series comes with insulated ice storage bin and door which minimizes air condensation and water formation on equipment surface. It produces steady and similar shape ice cubes with high transparency. It serves safe, hygienic, odorless and best tasting cube ices which can be used for all types of functions. The machine is configured using high quality material and advanced technology at par with ISO and CE standards. It has integrated design for maximum energy saving and water conservation.

Available Range :

Capacity : 3000 Kgs / 24 hrs Capacity : 230 kgs / 24 hrs Capacity : 195 kgs / 24 hrs Capacity : 636 kgs / 24 hrs Capacity : 160 kgs / 24 hrs Capacity : 295 kgs / 24 hrs
Capacity 900 kgs / 24 hrs
Storage Bin Capacity 460 kgs
Refrigeration System R404A
Cooling Mode Air/Water Cooling
Cooling Fan EBM(Germany)
Dry Filter Danfoss(Denmark)
Exterior Finish 304/2B Stainless steel
Compressor Brand Tecumseh (France)
Dimension (W x D x H) 840 x 1290 x 830 mm; 1300 x 950 x 1230 mm (2.39CBM)
Weight 245 kgs
Power Consumption 3800 W
Standard Voltage 1P / 220 V / 50 Hz
Certification CE
  • Corrosion resistant stainless steel is used
  • R404A refrigerant is used as refrigerant
  • User friendly technology
  • Overload protection
  • Constructed with stainless steel and rigid plastic cabinets and other high-quality components
  • Highly efficient, economical operation
  • Fully automatic control, indicator system to indicate of ice and water
  • Produces edible ice using potable water
  • Ambient temp. 20 °C, Inlet water temp. 10 °C

Cube ice makers are widely used in restaurants and other food service operations for cooling water and beverages. They are ideal for bars to enhance the appearance of alcoholic drinks due to clarity of ice. Often used in laboratories, hotels, marine fisheries, chemical industries, pharmaceutical industries etc.
