Polarizing Microscope

Labtron Polarizing Microscope is specialized to enhance contrast of transparent or translucent specimens. Their condenser improves luminescence focus, enhancing the clarity and quality of image. They feature light source that provides consistent illumination for optimal viewing of specimens. Their built-in camera systems allow for easy documentation and sharing of observations. Our Polarizing Microscope is suitable in forensics, art conservation, microelectronics, textiles, environmental science, and petrography.

Filter

Clear All

Microscope

Viewing Head

Eyepiece

Nosepiece

Condenser

Polarizing Microscope LPM-A10

Polarizing Microscope LPM-A10

Viewing Head: Siedentopf type binocular head, 30° inclined, eyepiece rotation 360ºInterpupillary adjustable distance 50 to 75 mm

Eyepiece: WF10X/20 mm, WF10X/20 mm (reticle 0.1 mm)

Nosepiece: Quintuple click stop revolving mechanism with multiple ball bearing

Condenser: Swing type N.A. 1.25 with iris diaphragm and filter

Polarizing Microscope LPM-A11

Polarizing Microscope LPM-A11

Viewing Head: Polarizing siedentopf trinocular head 30° inclined, eyepiece rotation 360°Interpupillary adjustable distance 48 to 76 mmLight distribution 100:1 (100% for eyepiece)

Eyepiece: WF10X/20 mm, WF10X/20 mm (reticle 0.1 mm)

Nosepiece: Quintuple, center adjustable

Condenser: Swing out type N.A. 0.9/0.13 polarizing unit, (with scale, rotable 3600, can be locked)

Polarizing Microscope LPM-A12

Polarizing Microscope LPM-A12

Non-Stress Infinity Plan Objective (Transmitting): PLAN 4x/ 0.10; W.D.= 12.1 mmPLAN 10x/ 0.25; W.D.= 4.64 mmPLAN 40x/ 0.66 (s); W.D.= 0.65 mmPLAN 60x/ 0.80 (s); W.D.= 0.33 mm

Eyepiece: WF10x/22 mm (adjustable)WF10x/22 mm (adjustable, reticule 0.1 mm)

Professional Polarizing Seidentopf Trinocular Head: Inclined 30°, Rotatable 360°, interpupillary distance: 48 mm to 76 mm

Light distribution: 100: 0 (eyepiece)80:20 (camera port)

Polarizing Microscope LPM-A13
Polarizing Microscope LPM-A13

Viewing Head: Seidentopf Trinocular Head, 30° inclined, 360° rotatable, interpupillary distance 48 to 76 mm

Eyepiece: SWF10x/22 mm, diopter adjustable, diameter 30 mm

Nosepiece: Quintuple, center adjustable

Non-stress infinity plan Objectives: PLAN 4x/0.10, W.D. = 12.1 mm PLAN 10x/0.25, W.D. = 4.64 mm PLAN 20x/0.40, W.D. = 2.41 mm PLAN 40x/0.66, W.D. = 0.65 mm

Polarizing Microscope LPM-A14
Polarizing Microscope LPM-A14

Optical System: Infinite Optical System

Viewing Head: Seidentopf Trinocular Head, inclined at 30°, 360° Rotatable

Eyepiece: WF10×/22 mm (Reticule 0.1mm)

Infinite Strain-Free Plan Achromatic Objective (Transmitted): 4×/0.10, 10×/0.25, 20×/0.40(S), 40×/0.66(S), 60×/0.80(S)

Polarizing Microscope LPM-A20

Polarizing Microscope LPM-A20

Optical System: Color Corrected Infinite Optical System

Viewing Head: Seidentopf Binocular Head, Inclined 30°, Rotatable 360°, Interpupillary Distance: 48-75mm

Eyepiece: WF 10×/18mm (Reticule 0.1mm)

Nosepiece: Quintuple click stop revolving mechanism with multiple ball bearing

Polarizing Microscope LPM-A21

Polarizing Microscope LPM-A21

Optical System: Color Corrected Infinite Optical System

Viewing Head: Seidentopf Trinocular Head, Inclined 30°, Rotatable 360°, Interpupillary Distance: 48-75mm Light Distribution 20:80 (Eyepiece: Trinocular Port)

Eyepiece: WF 10×/18mm (Reticule 0.1mm)

Nosepiece: Quintuple click stop revolving mechanism with multiple ball bearing

Polarizing Microscope LPM-B10

Polarizing Microscope LPM-B10

Optical System: Finite optical system

Viewing head: Trinocular viewing head, 30° inclined

Polarizing Attachment: Polarizer: Sliding in/out of optical path, located on the top of collector Analyzer: Rotatable analyzer with gradation 0°-90° Bertrand lens: Bertrand lens, sliding in/out of optical path Optical Compensator: λ Slip (first class red), 1/4λ Slip, Quartz wedge

Eyepiece: Eyepiece WF10X/18 with Division eyepiece 10X/18 mm 0.10 mm/div


Polarizing Microscope :
Polarizing Microscope LPM-A10, Polarizing Microscope LPM-A11, Polarizing Microscope LPM-A12, Polarizing Microscope LPM-A13, Polarizing Microscope LPM-A14, Polarizing Microscope LPM-A20, Polarizing Microscope LPM-A21, Polarizing Microscope LPM-B10, and more.
