| Measured Parameters | PM2.5, PM10, PM1.0, Temperature, Humidity, HCHO (Formaldehyde), TVOC |
| Temperature Range | -10°C to 50°C |
| Storage Temperature | -10°C to 60°C |
| Relative Humidity | 20% to 85% |
| Humidity Range | 20% to 85% |
| Atmospheric Pressure | 12.5 to 15.4 PSI |
| HCHO Measuring Range | 0.001 to 1.999 mg/m³ |
| TVOC Measuring Range | 0.001 to 9.999 mg/m³ |
| PM2.5/1/10 Measuring Range | 0 to 999 mg/m³ |
| Detection Method (HCHO/TVOC) | Electrochemistry Sensor |
| Detection Method (PM) | Laser Scattering |
| Sampling Time | 1.5 seconds |
| Power Supply | 3000 mAh |
| Dimensions | 145 × 78 × 97.2 mm |
| Weight | 235g |
Our Multi-Functional Air Quality Monitor is ideal for monitoring indoor air quality, detecting industrial pollution, HVAC analysis, and use in hospitals, schools, offices, labs, warehouses, smart cities, greenhouses, and homes.
USB Charge Cabel
Download catalog for
Multi-Functional Air Quality Monitor LAQM-B29 Catalog
Available Range :
CO2 Air Quality Monitor LAQM-G10 : CO2 Air Quality Monitor LAQM-B26 : CO2, PM2.5, PM1.0, PM10, AQI, HCHO (Formaldehyde), TVOC, Temperature, Humidity Air Quality Monitor LAQM-C10 : CO2, PM2.5, PM1.0, PM10, AQI, Temperature, Humidity, Time Air Quality Monitor LAQM-B11 : CO2, PM2.5, PM10, AQI, HCHO (Formaldehyde), TVOC, Temperature, Humidity, Clock Air Quality Monitor LAQM-B19 : CO2, PM2.5, PM10, AQI, HCHO (Formaldehyde), TVOC, Temperature, Humidity, Time Air Quality Monitor LAQM-B16 : CO2, PM2.5, PM10, AQI, HCHO, TVOC, Temperature, Humidity, Clock Air Quality Monitor LAQM-B20 : CO2, PM2.5, PM10, AQI, TVOC, HCHO(Formaldehyde), Temperature, Humidity, Date, Clock Air Quality Monitor LAQM-B25 : CO2, PM2.5, PM10, PM1.0, AQI, HCHO (Formaldehyde), TVOC, Temperature, Humidity, Date Air Quality Monitor LAQM-B10 : CO2, PM2.5, PM10, PM1.0, HCHO (Formaldehyde), TVOC, AQI, Temperature, Humidity Multi-Functional Air Quality Monitor LAQM-B28 : CO2, PM2.5, PM10, PM1.0, Temperature, Humidity Air Quality Monitor LAQM-B21 : CO2, PM2.5, PM10, PM1.0, TVOC, Temperature, Humidity, Date, Time Air Quality Monitor LAQM-B27 : CO2, Temperature, Humidity CO₂ Air Quality Monitor LAQM-G11 : CO₂ Wall-Mount Air Quality Monitor LAQM-J10 : CO₂, Decibel (Noise), Temperature, Humidity Air Quality Monitor LAQM-B14 : CO₂, PM2.5, PM1.0, PM10, AQI, HCHO, TVOC, Temperature, Humidity Air Quality Monitor LAQM-B17 : CO₂, PM2.5, PM1.0, PM10, AQI, HCHO, TVOC, Temperature, Humidity, Time Air Quality Monitor LAQM-B12 : CO₂, PM2.5, PM10, AQI, HCHO, TVOC, Temperature, Humidity Air Quality Monitor LAQM-B15 : CO₂, PM2.5, PM10, AQI, HCHO, TVOC, Temperature, Humidity, Clock Air Quality Monitor LAQM-B24 : CO₂, PM2.5, PM10, AQI, HCHO, TVOC, Temperature, Humidity, Date, Clock Air Quality Monitor LAQM-B13 : CO₂, PM2.5, PM10, HCHO, TVOC, AQI, Temperature, Humidity, Clock Wall Mount Air Quality Monitor LAQM-H10 : CO₂, PM2.5, Temperature, Humidity, Time Wall-Mount Air Quality Monitor LAQM-I10 : CO₂, PM2.5, Temperature, Humidity, Time/Date Multi-Functional Air Quality Monitor LAQM-B30 : Decibel (Noise), PM2.5, PM10, PM1.0, Temperature, Humidity Air Quality Monitor LAQM-D15 : O3 (Ozone) PM2.5, PM1.0, PM10, TVOC, Temperature, Humidity, AQI Wall-Mount Air Quality Monitor LAQM-I11 : PM2.5, HCHO (Formaldehyde), Temperature, Humidity, Time/Date Air Quality Monitor LAQM-D11 : PM2.5, PM1.0, PM10, AQI, HCHO (Formaldehyde), TVOC, Temperature, Humidity Air Quality Monitor LAQM-B23 : PM2.5, PM1.0, PM10, AQI, HCHO(Formaldehyde), TVOC, Temperature Humidity, Date, Clock Air Quality Monitor LAQM-D10 : PM2.5, PM10, PM1.0, HCHO (Formaldehyde), TVOC, Temperature, Humidity, AQI Multi-Functional Air Quality Monitor LAQM-B29 : PM2.5, PM10, PM1.0, Temperature, Humidity, HCHO (Formaldehyde), TVOC Mini PM2.5 Air Quality Monitor LAQM-E17 : PM2.5, Temperature, Humidity
Labtron Air Quality Monitors provide quick and efficient detection of various gases, temperature, humidity, and other parameters. These can detect a wide range of pollutants including fine particulate matter, larger particulate matter, volatile organic compounds, carbon dioxide, and more. They ensure complete monitoring of indoor and outdoor air quality. They store past air quality readings for trend analysis and comparison. Our Air Quality Monitor offers a battery-powered option for flexible and portable usage.
The monitor provides real-time measurements with a sampling time of 1.5 seconds, ensuring quick and accurate updates. This allows users to continuously monitor changes in air quality and take immediate action when necessary. The fast response time makes it ideal for both residential and industrial applications where air quality fluctuations need to be tracked efficiently.
The monitor operates between -10°C to 50°C, with a storage temperature range of -10°C to 60°C. This wide temperature tolerance makes it suitable for use in various indoor environments, including homes, offices, laboratories, and industrial settings. However, for optimal performance, it should be kept within the recommended operating range and away from extreme heat or freezing conditions.
The sensor detects particulate matter (PM) by analyzing how laser light scatters when it encounters airborne particles, providing real-time measurements. The intensity and pattern of the scattered light help determine the size and concentration of particles such as PM1.0, PM2.5, and PM10. This advanced detection method ensures high accuracy and is widely used in environmental monitoring, industrial safety, and indoor air quality assessments.
It is designed for both stationary and portable use, making it versatile for different monitoring needs. The compact and lightweight design allows for easy handheld operation, while its stable base ensures reliable placement on flat surfaces. Some models may also support wall mounting for continuous monitoring in fixed locations, making it ideal for homes, offices, laboratories, and industrial spaces.
The device displays real-time air quality readings, but specific alert functions may vary. Some models may include visual or audio indicators to notify users of poor air quality levels, helping them take timely action. For detailed information on alarm settings and customization options, please refer to the product manual or consult the manufacturer.
Air quality monitor is an important tool for improving air quality, protecting public health, and ensuring compliance with regulations. It can also be used to monitor climate change or support research and development.
Our air quality monitor can detect particulate matter (PM 2.5, PM 10), carbon monoxide, ozone, nitrogen dioxide, sulphur dioxide, volatile organic compounds.
Place the air quality monitor in an area with good airflow and don’t obstruct the air intake vent. For optimal sensor readings, keep your device away from direct sunlight and in open space that’s less than 500 square feet. Avoid placing your device near air vents, such as an AC or heater vent.
Our air quality monitor is ideally suited for use in homes, offices, industrial settings, and outdoor monitoring.
Air quality monitor is a device that measures the level of common air pollutants including both tiny and large particulate matter. They provide quick and efficient detection of various gases, temperature, humidity, and other parameters. Our air quality monitor ensure complete monitoring of indoor and outdoor air quality.
