Drying Oven LDO-A13

Drying Oven LDO-A13

Drying oven LDO-A13 comes with polished stainless steel chamber design. With double layered glass door, large observation window helps in inspection of the sample kept inside oven during process. Used in sterilization process with controlled heating applications and uniform distribution of air temperature.

Request Quote
Chamber Volume 136 L
Number of Shelves 2
Display Resolution 0.1℃
Temperature Range RT + 10 to 200°C / RT + 10 to 250°C
Temperature Stability ±1℃
Ambient Temperature 5 to 40°C
Timing Range 1 to 9999 min
Interior Dimension (W×D×H) 550×450×550 mm
Exterior Dimension (W×D×H) 840×580×730 mm
Power Consumption 2050 W
Power 220 V, 50 Hz
  • Polished stainless-steel chamber
  • 136 L Chamber Volume
  • Double layered glass door
  • Microprocessor based PID controller
  • Uniform air temperature distribution
  • Forced-air convection mode

Used in laboratories, testing and quality control plants, research institutes for desiccation, melting, sterilization, and other purposes.

Accessories No. Name
1 Programmable temperature controller
2 Independent temperature-limited system
3 25mm diameter test hole
4 RS485 port and software
5 Wireless alarm system(SMS alarm)

Compare Models

Model Chamber Volume Number of Shelves Display Resolution Temperature Range Temperature Stability Temperature Uniformity Ambient Temperature Timing Range Interior Dimension (W×D×H) Exterior Dimension (W×D×H) Power Consumption Power
LDO-A10 30 L 2 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 340×320×320 mm 620×440×490 mm 850 W 220 V, 50 Hz
LDO-A11 50 L 2 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 420×395×350 mm 720×530×520 mm 850 W 220 V, 50 Hz
LDO-A12 80 L 2 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 450×400×450 mm 740×530×630 mm 1550 W 220 V, 50 Hz
LDO-A13 136 L 2 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 550×450×550 mm 840×580×730 mm 2050 W 220 V, 50 Hz
LDO-A14 220 L 2 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 600×500×750 mm 880×720×930 mm 2450 W 220 V, 50 Hz
LDO-A15 420 L 3 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 640×585×1355 mm 780×750×1880 mm 3100 W 380 V, 50 Hz
LDO-A16 620 L 4 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 840×600×1355 mm 980×800×1880 mm 4000 W 380 V, 50 Hz
LDO-A17 1000 L 4 0.1℃ RT + 10 to 200°C / RT + 10 to 250°C ±1℃ - 5 to 40°C 1 to 9999 min 1000×600×1600 mm 1140×800×2150 mm 6000 W 380 V, 50 Hz
LDO-B10 50 L 2 0.1℃ RT + 10 to 200°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 375×370×370 mm - 700 W 220 V, 50 Hz
LDO-B11 100 L 2 0.1℃ RT + 10 to 200°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 455×430×510 mm - 1100 W 220 V, 50 Hz
LDO-B12 175L 3 0.1℃ RT + 10 to 200°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 560×530×595 mm - 1600 W 220 V, 50 Hz
LDO-C10 40 L 2 0.1℃ RT + 10 to 200°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 350×320×350 mm 480×566×650mm 850 W 220 V, 50 Hz
LDO-C11 80 L 2 0.1℃ RT + 10 to 200°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 400×350×500 mm 530×602×804mm 1550 W 220 V, 50 Hz
LDO-C12 150 L 3 0.1℃ RT + 10 to 250°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 500×360×800 mm 645×640×1114mm 2050 W 220 V, 50 Hz
LDO-C13 250 L 3 0.1℃ RT + 10 to 250°C ±1℃ ±2.5% 5 to 40°C 1 to 9999 min 520×460×1050 mm 665×730×1164mm 2450 W 220 V, 50 Hz
LDO-E10 - - - - - - - - - - - -
LDO-E11 - - - - - - - - - - - -
