Rotary Furnace LRTF-A12

Name: Rotary Furnace LRTF-A12
Brand: Labtron
SKU: LRTF-A12
Rating: 4.8 (929 reviews)

Rotary Furnace LRTF-A12 operates at a temperature range of 0 to 1100°C with a user-friendly touchscreen interface. It features a 304 stainless steel vacuum flange for enhanced sealing. The HD full-color LCD touchscreen display provides an intuitive interface for precise temperature control and monitoring. Its rotating and tilting mechanism ensures uniform coating and continuous production. Our furnace is ideal for the heat treatment of inorganic composite powders and coating of powder surfaces.

Request Quote

Operating Temperature	0 to 1100℃
Temperature Control Accuracy	± 1℃
Temperature Control	30 or 50 segment program
Constant Temperature Zone	200 mm
Furnace Tube Material	High purity quartz
Furnace Tube Diameter	Ф 100 mm
Furnace Tube Curvature	1500 mm
Furnace Length	440 mm
Heating Zone Length	400 mm
Sealed Type	304 stainless steel vacuum flange
Display Mode	HD full color LCD touch screen
RF Output System Power Range	0 to 500 W (adjustable)
RF Output System Operating Frequency	13.56 MHz ± 0.005%
RF Output System Working Mode	Continuous Output
RF Output System Reflected Power	≤ 3W
RF Output System Power Stability	≤ 2W
RF Output System Discharge Reflection Power	≤ 70W
RF Output System Harmonic Component	≤ -50 dBc
RF Output System Efficiency	≥ 70%
RF Output System Power Factor	≥ 90%
Cooling Type	Forced Cooling
Voltage	AC:220 V 50/60 Hz

High precision control
Adjustable power range
Compact design
Efficient cooling system
Low reflected power

Rotary Furnace LRTF-A12 is ideal to be used in material science laboratories, nanotechnology laboratories, research and development laboratories for heat treatment of inorganic composite powders, coating of powder surfaces, graphene preparation, and nanomaterial synthesis.

Download catalog for
Rotary Furnace LRTF-A12 Catalog

Available Range :

Rotary Furnace LRTF-A12 : 0 to 1100℃ Rotary Furnace LRTF-A13 : 0 to 1150℃

Models of Rotary Furnace

Labtron Rotary Furnace features cylindrical design for consistent and reliable thermal processing performance. They provide correct temperature regulation using advanced digital control systems for optimized heating processes. Their high-quality refractory lining ensures efficient insulation and energy conservation during operations. They incorporate an energy-efficient burner system for reduced fuel consumption and operational costs. Our Rotary Furnace is ideal for metallurgical, ceramic, and chemical industries.
