| Standard Capacity | 24 samples |
| Maximum Capacity | 192 samples simultaneously |
| Processing Time | Up to 192 samples within 1 minute |
| Homogenization Speed | 0 to 70 Hz (0 to 2100 rpm) |
| Grinding Methods | Wet grinding, dry grinding, low-temperature grinding |
| Maximum Feed Size | Adjustable according to adapters (no specific requirement) |
| Programmable Parameters | Running time: 0-9999s, Pause time: 0-999s, Run cycles: 1-99 times |
| Preset Programs | ≥24 groups for common plant and animal tissues |
| Temperature Range | -50°C to room temperature |
| Control Accuracy | ±1°C |
| Cooling Rate | Cools to below 0°C within 10 minutes of startup |
| Cooling Stage | Independent left-side cooling stage for short-term sample storage |
| Included Adapters | 2 x 242mL adapters |
| Compatible Tubes/Plates | 24*2ml, 48*2ml, 60*2ml, 96*2ml, 12*5ml, 10*10ml, 4*30ml, 2*50ml, 2*96-well plates |
| Adapter Design | Easy to disassemble |
| Safety Lock | Electromagnetic lock, screen-controlled, prevents opening during operation |
| Emergency Stop | Physical emergency stop button for immediate shutdown |
| Contamination Control | Closed-tube grinding to avoid cross-contamination |
| Transmission System | Slider transmission method (avoids optical axis wear) |
| Grinding Chamber | Unique square design for processing two 96-well plates |
| Noise Level | <65 dB |
| Display | ≥5 inch touchscreen |
| Bead Loader | Includes supporting bead loaders specifically developed for the grinder |
| Freezer Cover | Can cool electrophoresis transfer membranes (compatible with Servicebio systems) |
| Operating Environment Ambient Temperature | 5°C to 40°C |
| Operating Environment Relative Humidity | Max. 80% |
| Operating Altitude | Max. 2000 m |
| Operating Location | Indoor use only |
| Power Fluctuation | Must not exceed ±10% of rated value |
| Power Consumption | 800W |
| Input | 200-240 VAC, 50-60 Hz |
| Dimensions | 650 × 420 × 430 mm |
| Net Weight | 54 kg |
| Gross Weight | 65 Kg |
Square grinding chamber design
Operates at a low noise level
Electromagnetic safety lock
Slider transmission method
Multiple grinding methods
Flexible programming
Strong repeatability
Rapid cooling
Our Tissue Homogenizer LATH-A10 is specifically designed for the rapid, high-throughput homogenization of a wide range of biological samples. It is the ideal instrument for preparing plant tissues (roots, stems, leaves, seeds), animal tissues (heart, liver, spleen, lung, kidney, bone), and food products for downstream molecular analysis.
No. | Product Name | Quantity |
1 | Power Cable | 1 |
2 | Adapter (2mL × 48) | 1 |
3 | Adapter (2mL × 24) | 1 |
4 | Flower Nuts (Size mm: φ8) | 2 |
5 | Steel Bead Loader | 2 |
6 | Zirconia Bead Loader | 1 |
7 | Grinding Tubes (500 pieces/package) | 1 |
Adapters
Accessory Name | Qty |
0.5mL Tube Adapter (holds 24 tubes) | 1 pc |
2mL Tube Adapter (holds 24 tubes) | 1 pc |
2mL Tube Adapter, Solid (holds 24 tubes) | 1 pc |
2mL Tube Adapter (holds 32 tubes) | 1 pc |
2mL Tube Adapter (holds 48 tubes) | 1 pc |
2mL Tube Adapter, Solid (holds 48 tubes) | 1 pc |
2mL Tube Adapter (holds 60 tubes) | 1 pc |
2mL Tube Adapter (holds 96 tubes) | 1 pc |
5mL Tube Adapter, Steel (holds 6 tubes) | 1 pc |
10mL Tube Adapter (holds 10 tubes) | 1 pc |
15mL Tube Adapter, Steel (holds 8 tubes) | 1 pc |
30mL Tube Adapter, Steel (holds 4 tubes) | 1 pc |
50mL Tube Adapter, Steel (holds 2 tubes) | 1 pc |
96-Well Plate Adapter (holds 2 plates) | 1 pc |
30mL Tube Adapter, PTFE (holds 4 tubes) | 1 pc |
50mL Tube Adapter, PTFE (holds 2 tubes) | 1 pc |
Beads
Accessory Name | Qty |
Grinding Beads (Steel), 1.0 mm, 200g/box | 1 box |
Grinding Beads (Steel), 2.0 mm, 200g/box | 1 box |
Grinding Beads (Steel), 3.0 mm, 200g/box | 1 box |
Grinding Beads (Steel), 4.0 mm, 200g/box | 1 box |
Grinding Beads (Zirconia), 1.0 mm, 150g/box | 1 box |
Grinding Beads (Zirconia), 2.0 mm, 150g/box | 1 box |
Grinding Beads (Zirconia), 3.0 mm, 150g/box | 1 box |
Grinding Beads (Zirconia), 4.0 mm, 150g/box | 1 box |
Grinding Beads (Zirconia), 0.1 mm, 150g/box | 1 box |
Grinding Beads (Zirconia), 0.5 mm, 150g/box | 1 box |
Grinding Beads (Glass), 0.1 mm, 40g/box | 1 box |
Grinding Beads (Glass), 0.5 mm, 40g/box | 1 box |
Bead Pens
Accessory Name | Qty |
Bead Pen, Sterile (pre-loaded with 2.0 mm Steel Beads) | 1 pc |
Bead Pen, Sterile (pre-loaded with 3.0 mm Steel Beads) | 1 pc |
Bead Pen, Sterile (pre-loaded with 4.0 mm Steel Beads) | 1 pc |
Bead Pen, Sterile (pre-loaded with 2.0 mm Zirconia Beads) | 1 pc |
Bead Pen, Sterile (pre-loaded with 3.0 mm Zirconia Beads) | 1 pc |
Bead Pen, Sterile (pre-loaded with 4.0 mm Zirconia Beads) | 1 pc |
Accessories
Accessory Name | Qty |
Plum Handle for Adapter (Thread size: φ8 mm) | 1 pc |
Stainless Steel Nut for Adapter (Thread size: φ8 mm) | 1 pc |
Other Tubes
Accessory Name | Qty |
50mL Centrifuge Tube (RNase/DNase Free, V-bottom), 25pcs/bag | 1 pc |
10mL Centrifuge Tube, 100pcs/bag | 1 bag |
Tubes | 2.0mL Grinding Tubes (RNase/DNase Free), 500pcs/bag | 1 bag |
Download catalog for
Tissue Homogenizer LATH-A10 Catalog
Labtron Tissue Homogenizer is specialized to break down biological samples into uniform suspension by using mechanical forces. They are equipped with interchangeable probes, allowing customization based on sample type and viscosity. Their blades and motorized rotors provide high speed operation to physically break down tissues. They use high-frequency sound waves to create cavitation bubbles that disrupt cell membranes and release intracellular components. Our Tissue Homogenizer is ideal for protein extraction, DNA and RNA isolation, vaccine development and culturing.
