| Wavelength range | 190 to 1100 nm |
| Spectral bandwidth | 2 nm |
| Wavelength Accuracy | ±1 nm |
| Wavelength Repeatability | ≤0.5 nm |
| Optical system | Split Beam |
| Photometric Range | 0.0 to 200.0% T -0.301 to 4.000 A 0.000 to 9999 C |
| Photometric Accuracy | ± 0.5% T ± 0.004 Abs (0 to 0.5A) ± 0.008 Abs (0.5 to 1A) |
| Photometric repeatability | ≤0.2% T 0.002 Abs (0 to 0.5 A) 0.004 Abs (0.5 to 1 A) |
| Detector | Silicon Photocell |
| Stray light | ≤ 0.1%T (at 220nm Na I, 360 nm NaNo2) |
| Power supply | AC 220 V ± 22 V 50 Hz ± 1Hz, 180 W |
| Noise | 100%(T) noise ≤ 0.2% (T) ， 0%(T) noise ≤ 0.1% (T) |
| Baseline flatness | ≤ ± 0.002 A (200 to 1090 nm) |
| Scanning speed | Fast - Medium - Slow |
| Wavelength setting | 7-inch color touchscreen |
| Display | 7-inch color touchscreen |
| Dimension | 630 × 535 × 405 mm |
| Gross weight | 21 kg |
Split Beam UV-Vis Spectrophotometer is widely used for analysis of the samples across hospitals, biochemical, petrochemical, environmental protection industries and universities.
Download catalog for
Split Beam UV-Vis Spectrophotometer LUS-D10 Catalog
Labtron UV Vis spectrophotometers come with various wavelengths and ARM-processed cores. They have touch screen interfaces and automatically adjusted wavelengths. They have automatic zero and full scale adjustments, USB connectors, and optional internal printers. These spectrophotometers include sample chambers for convenient handling and use. They provide accurate automated changeovers, concentration factor changes, and direct concentration read-outs. Our UV Vis spectrometers are efficient and easy to use because of their sophisticated technology, which streamline gadget operation.
Labtron Split Beam UV-Vis Spectrophotometer is widely used in clinical diagnostics, environmental monitoring, petrochemical analysis, and academic research. It offers abroad wavelength range from 190 to 1100 nm, making it suitable for measuring nucleic acids, proteins, colorimetric assays, and chemical compositions. It is also valuable in quality control for industrial processes. Our spectrophotometer's accuracy and reproducibility make it ideal for demanding analytical tasks.
Our Split Beam UV-Vis Spectrophotometer features a 7-inch full-color touchscreen for intuitive navigation and parameter setting. Automatic wavelength and T/A (Transmittance/Absorbance) changeovers simplify operation, making it accessible even for less experienced users. The direct concentration readout and concentration factor setting minimize manual calculations. These features streamline workflows and reduce user error.
The Split Beam UV-Vis Spectrophotometer includes automatic zero and full-scale adjustment to prevent incorrect readings. Its stable housing and internal design minimize light leakage and stray light exposure. Additionally, the reliable power system and automatic settings reduce the chance of operator-induced damage. These features together support safe, consistent performance in daily use.
Yes, our Split Beam UV-Vis Spectrophotometer is compatible with cuvettes ranging from 5 to 100 mm in path length, allowing flexibility for diverse sample types and analysis needs. This is particularly advantageous when working with limited sample volumes or requiring extended path lengths for low-concentration detection. The adjustable sample compartment accommodates various experimental setups. This versatility enhances its utility across multiple applications.
Labtron's Split Beam UV-Vis Spectrophotometer, equipped with a USB port, allows easy data transfer to external devices for storage, analysis, or reporting. This facilitates better record-keeping and integration with laboratory information management systems. An optional internal printer is available for immediate printouts of results. These features make data management more efficient and organized.
