Portable SF6 Dew Point Analyzer LSFD-A10

Name: Portable SF6 Dew Point Analyzer LSFD-A10
Brand: Labtron
SKU: LSFD-A10
Rating: 4.8 (696 reviews)

Portable SF6 Dew Point Analyzer LSFD-A10 offers an impressive dew point measurement range of -80℃ to +20℃ and moisture measurement range from 0 to 19,999 μL/L. It features an intelligent self-calibration technology that ensures precise and stable readings. The device can store up to 50 test results, and data is displayed clearly on an LCD screen. Its automatic dryer function significantly reduces measurement time, improving efficiency. Our analyzer is useful for maintaining the integrity of SF6 gas in power systems.

Request Quote

Gas Measured	SF6
Dew Point Measurement Range	- 80℃ to + 20℃
Moisture Measurement Range Value	0 to 19999 μL/L
Dew Point Measurement Accuracy	± 0.5℃ (- 60℃ to + 20℃) ± 1.0℃ (- 80℃ to - 60°C)
Dew Point Value Resolution	0.1℃
Moisture Value Resolution	1 μL/L
Response Time(- 60℃ to + 20℃) (0.1 MPa)	63% in 5 s, 90% in 45 s
Response Time(+ 20℃ to - 60℃) (0.1 MPa)	63% in 10 s, 90% in 240 s
Sampling Flow Rate	0.6 L/min
Flow Rate Variation	± 20%
Pressure Range	0 to 1.0 MPa
Temperature Range	- 20°C to + 60°C
Humidity Range	0 to 100% RH
Storage Temperature	- 20℃ to + 80℃
Charging Time	4 hours
Dimension	250 × 150 × 300 mm
Weight	3.5 kg
Gross Weight	5 kg

Rapid response
Self-locking joint
User-friendly interface
RS232 interface
Built-in power supply

Portable SF6 Dewpoint Analyzer LSFD-A10 is used in power systems, petroleum, chemical, and metallurgical industries, as well as research institutes, to monitor and control the moisture content of SF₆ gas.

3 Meter Intake pipe × 1 piece

3 Meter Bleeder pipe × 1 piece

Transition joint (1 to 8) × 1 piece

Raw material belt × 1 piece

RS232USB cable × 1 piece

Charger × 1 piece

Disk × 1 piece

Download catalog for
Portable SF6 Dew Point Analyzer LSFD-A10 Catalog
