What is the purpose of the Aluminium Foil Pinhole Detector?

The detector identifies tiny pinholes and defects in aluminum foils to ensure quality and prevent contamination in packaging and industrial applications.

What is the minimum pinhole size that Labtron’s LAPD-A10 can detect?

The LAPD-A10 can detect pinholes as small as 0.01 mm with high precision.

How does the detector enhance accuracy during inspection?

It features a 100X objective magnification and a high light transmittance glass liner plate for clear visibility and precise detection.

Does the detector offer adjustable power settings?

Yes, it is equipped with two gear switches that allow three different power combinations for flexible operation.

Aluminium Foil Pinhole Detector LAPD-A10

Name: Aluminium Foil Pinhole Detector LAPD-A10
Brand: Labtron
SKU: LAPD-A10
Rating: 4.7 (768 reviews)

Aluminium Foil Pinhole Detector LAPD-A10 offers high precision, measuring down to 0.02 mm. With a 100X objective magnification, it ensures detailed inspection of small defects. Its high light transmittance glass liner plate provides clear visibility for accurate detection. Equipped with two gear switches, it allows three different power combinations for versatile operation. Our aluminium foil pinhole detector is ideal for industries such as pharmaceuticals, food packaging, electronics, aerospace, automotive, battery manufacturing, and printing.

Request Quote

Minimum Resolution Grid Value	0.02 mm
Objective Magnification	100X
Maximum Measuring Aperture	1.6 mm
Light Source Power	30W
Application Environment Illumination	20 to 50 Lux
Laboratory temperature	23°C ± 2°C
Humidity	50% ± 10% RH
Frame Size	400 × 250 mm
Dimensions	800 × 600 × 300 mm
Net Weight	28 Kg

100X HD magnification
Compact
Easy operation
Hassle free maintenance

Aluminium Foil Pinhole Detector LAPD-A10 is used in industries like pharmaceuticals, food packaging, electronics, aerospace, automotive, battery manufacturing, and printing.

Microscope

Light tube

Download catalog for
Aluminium Foil Pinhole Detector LAPD-A10 Catalog

Portable Vibration Calibrator LPVC-B10

Vibration Frequency Range : 10 Hz to 10,000 Hz (adjustable)
Vibration Frequency Accuracy : Up to 0.1%
Vibration Amplitude Range : 0 to 100 m/s² (adjustable)
Amplitude Linearity : Up to 1%

Compare Remove

Portable Vibration Calibrator LPVC-A10

Frequency (continually adjustable) : 10 Hz to1280 Hz + 0.01 %
Amplitude acceleration ( at 30m/s2 pk ) : 40 Hz to 320 Hz + 0.3 dB + 1 digit
Amplitude velocity ( at 25mm / sec pk ) : 40 Hz to 320 Hz + 0.5dB +1 digit
Amplitude displacement ( at 50 μm pk-pk ) : 40 Hz to 320 Hz + 0.5 dB + 1 digit

Compare Remove

The detector identifies tiny pinholes and defects in aluminum foils to ensure quality and prevent contamination in packaging and industrial applications.
The LAPD-A10 can detect pinholes as small as 0.01 mm with high precision.
It is widely used in pharmaceuticals, food packaging, electronics, aerospace, automotive, battery manufacturing, and printing industries.
It features a 100X objective magnification and a high light transmittance glass liner plate for clear visibility and precise detection.
Yes, it is equipped with two gear switches that allow three different power combinations for flexible operation.
