| Capacity | 225 L |
| Temperature Range | - 70 ℃ to 150 ℃ (Optional + 180 ℃) |
| Temperature Uniformity | Less than or equal to 2.0 °C |
| Temperature Fluctuation | ± 0.5 ℃ |
| Heating Rate | - 70 ℃ to + 100 ℃ (3 ℃/min) |
| Cooling Rate | + 20 ℃ to – 70 ℃ (3 ℃/min) |
| Operating Ambient Temperature | 5 °C to 35 °C |
| Floor Space | 1.3 m² |
| Controller | 7-inch touch screen controller |
| Communication Interface | USB, RS-232/485, and LAN |
| Refrigeration System | Hermetic compressor, single stage or cascade refrigeration system |
| Interior Chamber Material | SUS304 stainless-steel plate |
| Exterior Chamber Material | High quality cold rolled steel plate, surface electrostatic powder coating |
| Insulation Material | Rigid polyurethane foam insulation layer, flame retardant grade B2 |
| Power Consumption | 6 KW |
| Power supply | AC 380V ±10% 50Hz / AC 220V ±10% 50Hz |
| Internal Dimensions | 700 × 700 × 480 mm |
| External Dimensions | 900 × 1735 × 1505 mm |
| Package Dimensions | 1110 × 2100 × 1750 mm |
| Net Weight | 430 Kg |
| Gross Weight | 580 Kg |
Power Recovery Restart Function
Digital Temperature Control Panel
Water Shortage Protector
Single Stage Refrigeration System
Durable and Robust Construction
Our chamber is ideal for evaluating the durability, reliability, and thermal response of weapons systems, wearable electronics, flexible packaging films, sealing components, and food containers under diverse storage environments.
Accessories | Quantity | Unit |
Observation Window light | 1 | Set |
Mobile casters (with foot cups) | 4 | Pieces |
Cable ports (50 mm with silicone plugs) | 2 | Units |
Sample racks | 2 | Layers |
Internal lighting | 1 | Set |
Power cord | 5 | Meters |
Download catalog for
High-Low Temperature Test Chamber LTTC-C22 Catalog
Labtron Temperature Test Chambers are designed for controlled environmental testing across industrial and research applications. They feature a balanced temperature control system, ensuring uniform heating and cooling for stable performance. These chambers have SUS304 stainless steel interiors with advanced insulation to enhance efficiency and durability. Their programmable touchscreen controller allows easy operation with multiple communication interfaces for smooth data transfer. Our Temperature Test Chambers are ideal for reliability testing, material evaluation, and electronic component assessments.
Yes, the High-Low Temperature Test Chamber LTTC-C22 offers integration capabilities via RS-232, USB, or optional Ethernet interfaces. It can communicate with external DAQ systems and transfer test data in real time. Compatibility with LabVIEW and similar platforms enables full system control and data logging externally. Users can also import/export temperature profiles for repeat testing. This is particularly beneficial for labs needing centralized data collection. Password protection ensures secure remote access. Integration expands flexibility in test automation and compliance validation.
The High-Low Temperature Test Chamber LTTC-C22 features rapid recovery technology to restore the internal temperature quickly after door openings. High-speed circulation fans and pre-cooled air reserves help re-establish set conditions efficiently. It also includes door-open detection sensors that pause the test cycle to prevent skewed results. Once the door is closed, the system resumes the profile from the correct phase. An automatic lock can be engaged during sensitive cycles. LED indicators and alarms alert users to unauthorized or accidental openings. These safeguards maintain test integrity even during brief interruptions.
Programmable profiles allow for automation of complex testing sequences without manual intervention. Users can define temperature setpoints, hold times, ramp rates, and cycle counts. This is especially useful for simulating real-world environmental fluctuations. The touchscreen controller simplifies step-by-step programming with graphical visualization. Profiles can be saved, reused, or exported for consistency across tests. Conditional logic can also be applied to trigger alarms or transitions. These capabilities support comprehensive product qualification routines.
The High-Low Temperature Test Chamber LTTC-C22 includes ambient temperature compensation that maintains internal precision even if room conditions vary. It is designed to operate optimally within a specified ambient range (typically +5? to +35?). Insulated panels and air seals protect against external heat ingress. If ambient temperature exceeds limits, the system alerts users to avoid test deviations. Built-in cooling load management ensures consistent operation under stress. HVAC-independent operation enables placement flexibility. Overall performance remains reliable regardless of minor environmental shifts.
Yes, the High-Low Temperature Test Chamber LTTC-C22 is equipped for remote access via Ethernet or Wi-Fi, depending on configuration. Authorized users can perform diagnostics, adjust parameters, and download logs without being physically present. Firmware updates can be pushed through secure connections to enhance features or resolve issues. Error codes and self-test reports are accessible remotely. Cloud backup of test data can also be enabled. This reduces downtime and allows faster support response. Remote management boosts operational efficiency across distributed teams.
