Tube Furnace LTF-A11

Name: Tube Furnace LTF-A11
Brand: Labtron
SKU: LTF-A11
Rating: 4.7 (974 reviews)

Tube Furnace LTF-A11 is an extended type tube furnace comprised with 8 step heating programs, offers continuous working temperature of 1100°C with 250 mm heated zone. Features K type thermocouples for accurate measurement and temperature control with high precision and 4 preset programs. Equipped with thermal shock resistant tubes, 4 lines LCD display, and software based PID control, this tube furnace has gas inlet and evacuation system option for protective atmosphere. Designed with dual shell housing and durable inside lining of light insulating bricks, it is an ideal unit for homogeneous temperature distribution and reliable protective atmosphere with lift up and sidewards opening door possibilities.

Request Quote

Type	Extended
Program memories	4
Heating program	8 step
Working temperature	1100°C
Tube length	420 mm
Tube diameter	20 mm
Heated zone	250 mm
Thermal rate	1 to 20°C/ min
Homogeneous Hot Zone	84 mm at ± 10°C
Thermocouple	K-type
Heating element	Fe-Cr-Al
Inner insulation material	Ceramic-fibre blanket
Housing	Steel sheet with epoxy powder coating
Display	4 lines
Maximum current	5A
Power	1100 W
Dimension (W×D×H)	424×315×420 mm
Net weight	14 kg
Packaging dimension (W×D×H)	470×361×579 mm
Gross weight	20 kg

Extended type tube furnace comprised with 8 step heating programs
Continuous working temperature of 1100°C with 1 to 20°C/min of thermal rate
K type thermocouples for accurate measurement and temperature control
Thermal shock resistant tubes to withstand extreme and rapid changes in temperature
4 lines LCD display with easy-to-understand menu and Programming
Software based PID control, ensures stability and accuracy
Gas inlet and evacuation system option for protective atmosphere
Dual shell housing and durable inside lining of light insulating bricks
An ideal unit for homogeneous temperature distribution and reliable protective atmosphere
With lift up and sidewards opening door possibilities
High-efficient, stable and reliable

Tube furnace is used for purification, coating, drying, hardening or ageing of samples, for annealing, brazing, calcination, degassing, sintering, soldering, sublimation, synthesis, and tempering, thermocouple calibration, in the testing of fuel cells, or in catalyst research.

Download catalog for
Tube Furnace LTF-A11 Catalog

Available Range :

Tube Furnace LTF-A11 : Extended Tube Furnace LTF-B13 : Scientific Tube Furnace LTF-A10 : Standard Tube Furnace LTF-B12 : Ultimate
