Tube Furnace LTF-B24

Name: Tube Furnace LTF-B24
Brand: Labtron
SKU: LTF-B24
Rating: 4.9 (941 reviews)

Tube Furnace LTF-B24 is a standard type of tube furnace comprised with 660 mm tube length and 50 mm diameter with 450 mm heat zone and 1200°C continuous working temperature. Features software based PID control with 4 lines LCD display and 4 steps heating program with 2 preset programs and 1 to 20°C/min of thermal rate. With K-type thermocouple and thermal shock resistant tubes, it can withstand extreme and rapid changes in temperature. Designed with dual shell housing and durable inside lining of light insulating bricks, this tube furnace is with gas inlet and evacuation system option for protective atmosphere, makes it an ideal unit for homogeneous temperature distribution and reliable protective atmosphere.

Request Quote

Type	Standard
Program memories	2
Heating program	4 steps
Working temperature	1200°C
Tube length	660 mm
Tube diameter	50 mm
Heated zone	450 mm
Thermal rate	1 to 20°C/min
Homogeneous Hot Zone	150 mm at ±10°C
Thermocouple	K-type
Heating element	Fe-Cr-Al
Inner insulation material	Ceramic-fibre blanket
Housing	Steel sheet with epoxy powder coating
Display	4 lines
Maximum current	7A
Power	1500 W
Dimension (W×D×H)	634×384×476 mm
Net weight	29 kg
Packaging dimension (W×D×H)	675×430×635 mm
Gross weight	37 kg

Standard type tube furnace design with 660 mm tube length and 50 mm diameter with 450 mm heat zone and and 1200°C continuous working temperature
Software based PID control with 4 lines LCD display, ensures precision and stability
Steps heating program with custom preset program and 1 to 20°C/min of thermal rate
K-type thermocouple and thermal shock resistant tubes
Can withstand extreme and rapid changes in temperature
Dual shell housing and durable inside lining of light insulating bricks
Gas inlet and evacuation system option for protective atmosphere
An ideal unit for homogeneous temperature distribution and reliable protective atmosphere
High-efficient, precise, stable and reliable with easy and convenient operation

Tube furnace is used for purification, coating, drying, hardening or ageing of samples, for annealing, brazing, calcination, degassing, sintering, soldering, sublimation, synthesis, and tempering, thermocouple calibration, in the testing of fuel cells, or in catalyst research.

Download catalog for
Tube Furnace LTF-B24 Catalog

Available Range :

Tube Furnace LTF-A11 : Extended Tube Furnace LTF-B13 : Scientific Tube Furnace LTF-A10 : Standard Tube Furnace LTF-B12 : Ultimate

Models of Tube Furnace

Labtron Tube Furnaces come with an LCD with an easy-to-understand menu for user-friendly operation. These feature a gas inlet and evacuation system option for maintaining a protective atmosphere. Their thermal shock-resistant tubes are designed to withstand extreme and rapid temperature changes. They offer a step heating program and customizable preset programs for precise temperature control. Our Tube Furnaces are made of dual-shell housing for enhanced thermal efficiency.
