| Type | Microscopic |
| Wavelength Range | 360 to 1100 nm |
| Spot Size | 60 µm |
| Spectral Resolution | 1 nm, 5 nm |
| Wavelength Accuracy | ±0.5 nm |
| Measurement Method | Comparison with reference sample |
| Measurement Error | Up to ±2% (0 to 100%) |
| Objective Lens | 10x half-width objective lens |
| Sample Curvature Compatibility | -1R to ∞ to +1R to ∞ |
| Observation Method | Eyepiece + CCD camera |
| Reflection Test Light Source | Halogen lamp 12V 100VA |
| Focus Light Source | 6000K LED |
| Reflectance Ratio Range | 0 to 100% |
| Integration Measurement Time | Up to 1 second to 5 seconds |
| Repeatability Error | Up to 0.5.% |
| PC Interface | USB mode |
| Power Supply | AC 210 to 240V 50/60 Hz 200 VA |
Our Reflectivity Tester LRFT-C10 accurately measures spectral reflectance and coating uniformity, even on complex surfaces like lenses. Its ability to eliminate back reflection and focus on microscopic spots ensures precision in evaluating transparent materials. The system supports colorimetric analysis, making it valuable in optical quality control and R&D. It is ideal for industries requiring high-accuracy reflectance and color measurement at the microscale.
Download catalog for
Reflectivity Tester LRFT-C10 Catalog
Labtron offers a wide range of Reflectivity Testers that are designed to measure the reflectivity and reflectivity curves of various objects. They are also analyzing the color characteristics of the materials and enabling the simultaneous detection. Their compliance with various national standards makes them reliable for industrial and laboratory-grade testing environments. They adopt the integrating sphere method, allowing customized measurement angles based on specific application needs. Our Testers are widely applied across industries such as electronics, automotive, optics, materials science, and display manufacturing.
