Touch Screen Melting Point Apparatus LDMP-B14

Touch Screen Melting Point Apparatus LDMP-B14

Touch Screen Melting Point Apparatus LDMP-B14 consists of high precision temperature control to ensure stable and reliable results. It offers automatic detection and real time display of data for measuring the melting point of sample accurately. Equipped with HD video camera technology for observing the entire process of sample’s melting point.

Request Quote
Temperature control range Room temperature to 420 ℃
Detection method Fully automatic
Capacity per batch 4 pcs/batch
Temperature resolution 0.01 ℃
Temperature accuracy ± 0.3℃
Heating rate 0.1 ℃ to 20℃(200 gears, steplessly adjustable)
SD card capacity 128G
Interface USB RS232, SD, Wi-Fi, RJ45, U disk
Temperature control mode PID precise temperature control, completely enclosed furnace body design
Accuracy ±0.2℃ (<250℃), ±0.4℃ (>250℃)
Repeatability ± 0.1℃ at 0.1℃/min
Magnification 9 times
Display FTF color touch color screen
Data storage 128G
Map save 600 groups
Map Any zoom
User Management Level YES / Level 4 authority
Audit trails YES
Electronic signature YES
Custom method libraries YES
Export file verification advanced protection MD5 YES
Small capillary size OD: Φ1.3mm, ID: Φ1.1mm
Large capillary size OD: Φ4.2mm, ID: Φ3.8mm
Power supply 110 to 230V, 50/60 Hz
Power 120 W
Dimension 400 × 280 × 330 mm
Weight 4.1 kg
  • Provides a wide range of temperatures, from ambient temperature to 420 °C
  • Adjustable heating rate from 0.1 to 20 degrees Celsius per minute HD video camera technology makes it simple to see and record the entire melting process
  • Excellent flexibility as users can regulate how quickly a drug changes from a solid to liquid state
  • A sizable, high-definition color screen that gives users an easy-to-use interface
  • Multi-sample testing, which increases productivity and efficiency in a laboratory setting by simultaneously determining the melting points of up to 4 samples
  • Users can attach a printer to the device to print real-time data

Touch Screen Melting Point Apparatus is widely used for determining melting point of the substances across chemical industries, pharmaceuticals, medicinal research, academics, and research institutions.

Printer

Compare Models

Model Temperature control range Detection method Capacity per batch Temperature resolution Temperature accuracy Heating rate SD card capacity Interface Temperature control mode Accuracy Repeatability Magnification Display Data storage Map save Map User Management Level Audit trails Electronic signature Custom method libraries Export file verification advanced protection MD5 Small capillary size Large capillary size Power supply Power Dimension Weight
LDMP-A12 - - - - - - - - - ±0.4°C (˂ 250°C), ± 0.7°C (˃ 250°C) When 0.1°C/Min, repeatability ± 0.3°C - FTF high resolution Colourful touch screen - - - - - - - - - - - - 250 mm × 250 mm × 150 mm 1.2 kg
LDMP-A13 - - - - - - - - - ±0.4°C (˂ 250°C), ± 0.7°C (˃ 250°C) When 0.1°C/Min, repeatability ± 0.3°C - FTF high resolution Colourful touch screen - - - - - - - - - - - - 250 mm × 250 mm × 150 mm 1.2 kg
LDMP-A20 - - - 0.1 ℃ - 0.1 ℃ / min or 20 ℃ / min - - - ± 0.3 ℃ (< 200 ℃) , ±0.5℃(>200℃) Melting point repeatability ± 0.1 ℃ at 0.1 ℃ / min ≥ 10 - - - - - - - - - - - 220 V, 50 Hz - - -
LDMP-B10 RT to 100℃ Semi-automatic 2 pcs/batch 0.1℃ ±0.3℃ - 8G USB RS232 SD card Enternet - - 0.1℃/Min , ±0.1℃ - TFT Touch screen - - - - - - - - - - - 110 to 220V 50, 60HZ 120W 400 × 280× 330 mm 5 kg
LDMP-B11 6 to 100℃ Semi-automatic 2 pcs/batch 0.1℃ ±0.3℃ - 8G USB RS232 SD card Enternet - - 0.1℃/Min , ±0.1℃ - TFT Touch screen - - - - - - - - - - - 110 to 220V 50, 60HZ 120W 400 × 280× 330 mm 5 kg
LDMP-B12 RT to 100℃ Fully automatic (compatible with Semi-automatic) 2 pcs/batch 0.1℃ ±0.3℃ - 8 G USB RS232 SD card Enternet - - 0.1℃/Min , ±0.1℃ - TFT Touch screen - - - - - - - - - - - 110 to 220V 50, 60Hz 120W 400 × 280× 330 mm 5 kg
LDMP-B13 4 to 100℃ Fully automatic (compatible with Semi-automatic) 2 pcs/batch 0.1℃ ±0.3℃ - 16 G USB RS232 SD card Enternet - - 0.1℃/Min , ±0.1℃ - TFT Touch screen - - - - - - - - - - - 110 to 220V 50, 60Hz 120W 400 × 280× 330 mm 5 kg
LDMP-B14 Room temperature to 420 ℃ Fully automatic 4 pcs/batch 0.01 ℃ ± 0.3℃ 0.1 ℃ to 20℃(200 gears, steplessly adjustable) 128G USB RS232, SD, Wi-Fi, RJ45, U disk PID precise temperature control, completely enclosed furnace body design ±0.2℃ (<250℃), ±0.4℃ (>250℃) ± 0.1℃ at 0.1℃/min 9 times FTF color touch color screen 128G 600 groups Any zoom YES / Level 4 authority YES YES YES YES OD: Φ1.3mm, ID: Φ1.1mm OD: Φ4.2mm, ID: Φ3.8mm 110 to 230V, 50/60 Hz 120 W 400 × 280 × 330 mm 4.1 kg
