Air Jacketed CO2 Incubator LAJI-C21

Name: Air Jacketed CO 2 Incubator LAJI-C21
Brand: Labtron
SKU: LAJI-C21
Rating: 4.9 (710 reviews)

Air Jacketed CO₂ Incubator LAJI-C21 is a cooling and shaking incubator comprising single orbital platform with triple eccentric shaft balance drive, offers 40 to 300 rpm of speed. Adopted with six sides direct heating, auto-adjustable cycle fan speed, door heating system, and compressor this incubator offers continuous operation within 0 to 5999 min and 4 to 65°C of temperature range. Fluorine-free design with 304 stainless steel chamber, shelves, and platform with round curved corners, it is a load bearing structure provide excellent durability and performance. Equipped with IR sensor, color touch screen controller, password lock function, 90° high temperature and sterilization system, it has unique air duct design. With CO₂ concentration sensor, advanced alarm system, temperature control and monitoring system, Micro-biological & HEPA filter this incubator ensures controlled, uniform and stable conditions.

Request Quote

CO₂ range	0-20%
CO₂ recover time	(Return to 5% after opening the door for 30 seconds) ≤3 mins
CO₂ control accuracy	±0.1%
CO₂ stability of 5%CO₂	±0.1%
CO₂ uniformity	±0.1%
CO₂ sensor	IR CO₂ sensor
Shaking frequency	40 to 300 rpm
Drive way	Three eccentric shaft balance drive type
Humidity control	50 to 90% RH
37°C humidity control accuracy	85% to 95% RH
Humidity resolution	0.001
Humidity deviation	±2%
Allowable shaking load	15 kg
Temperature control range	4 to 65° C
Temperature uniformity	±0.5° C (test point at 37°C)
Ambient temperature	25°C
Heating method	6 side direct heating
Sterilization method	90˚ C moist heat sterilization
Timing range	0 to 5999 min
Platform movement	Orbital
Platform size (L×B)	450×450 mm (1pc)
Shelf	3 pcs
Display	Colorful touch screen controller
Sterilization system	90° high temp. high humidity sterilization system
Filter	Microbiological and HEPA filter
Motor	Low heat rejection brushless DC motor
Interface	RS485
Alarm system	Temperature deviation, over temperature, high/low speed, door open, high/low CO₂ condensation, disinfection and sterilization reminder, auto cut-off of heat and fan, and auto-stop
Orbital diameter	20 mm+AO2
Interior dimension (W×D×H)	605×700×520 mm
Exterior dimension (W×D×H)	793×975×853 mm
Gross Weight	98 kg (approx.)
Power	1800 W
Voltage	220V 50Hz
Flask Configuration	50 ml×36, 100 ml×23, 250 ml×13, 500 ml×8, 1 L×5, 2 L×3, 4 L×1, 5 L×1

CO₂ cooling and shaking incubator with air jacketed configurations
Single orbital platform with triple eccentric shaft balance drive
6 sides direct heating with auto-adjustable cycle fan speed
Door heating system at outer door and large toughened inner glass door for observation
Continuous operation within 0 to 5999 min and 4 to 65°C of temperature range
Fluorine-free design with 304 stainless steel chamber, shelves, and platform with round curved corners
Low heat rejection brushless DC motor with high start torque
CO₂ control and monitoring system with IR sensors
Pollution proof control with Micro-biological & HEPA filter
90° high temperature and sterilization system for thoroughly sterilization of chamber
Large color touch screen controller with password lock function
Unique air duct design with high quality compressor
Load bearing structure provide excellent durability and performance
Alarm system: Temperature deviation, over temperature, high/low speed, door open, high/low CO2 condensation, disinfection and sterilization reminder, auto cut-off of heat and fan, and auto-stop
High- efficiency, with low power consumption

Air Jacketed CO2 Incubator are used for tissue engineering, cell culture, in vitro fertilization, diagnostics, neuroscience, cancer research and for developing biosensors across medical research, pharmaceutical industry, scientific research, laboratories, etc.

Download catalog for
Air Jacketed CO2 Incubator LAJI-C21 Catalog

Available Range :

Air Jacketed CO2 Incubator LAJI-C10 : (0~20)% V/V Air Jacketed CO₂ Incubator LAJI-C20 : 0-20%

Models of Air-jacketed CO2 Incubator

Labtron Air-Jacketed CO2 Incubator is specialized to maintain optimal condition with chamber volume of 40 L to 570 L. Their dual-layer construction ensures stable internal temperature and protects against external fluctuations effectively. They are equipped with carbon dioxide monitoring system to measure accurate gas concentration levels. Their humidity control system prevents dehydration of cell cultures, promoting healthy growth environments consistently. Our Air-Jacketed CO2 Incubator culture sensitive cells and tissues for stem cell research and genetic engineering.

Air Jacketed CO₂ Incubator LAJI-D10

Capacity : 570 L
Temperature Range : 5 to 40 °C
Ambient Temperature : 5 to 60 °C
Accuracy : 0.1 °C

Compare Remove

Air Jacketed CO2 Incubator LAJI-B11

Chamber Volume : 80 L
Shelves : 2 (pcs)
Heating Method : Air-jacketed, PID Control
Temperature Range : RT + 5 to 50°C

Compare Remove

Air Jacketed CO2 Incubator LAJI-C12

Chamber Volume : 155 L
Shelves : 3
Heating Method : Air-jacketed
Temperature Range : RT+5 ℃ to 50 ℃

Compare Remove

Air-Jacketed CO₂ Incubator LAJI-E11

Capacity : 175L
Ambient Temperature : 19℃ to 25℃
Display Screen : 4.3-inch color touchscreen
Temperature Control Range : Room temperature +3℃ to 55℃

Compare Remove

Air Jacketed CO2 Incubator LAJI-B16

Heating Method : Direct Heating Air Jacket Type
Capacity : 55 L
Temperature Range : RT+3 to 60℃
Temperature Uniformity : Less than or equal to ±0.25℃

Compare Remove

Air Jacketed CO2 Incubator LAJI-B18

Heating Method : Direct Heating Air Jacket Type
Capacity : 260 L
Temperature Range : RT+3 to 60℃
Temperature Uniformity : Less than or equal to ±0.25℃

Compare Remove

Air Jacketed CO2 Incubator With UV Sterilization LAJI-F22

Sterilization Method : UV sterilization
Capacity : 260 L
Temperature Range : RT+5 to 55℃
Ambient temperature range : 18 to 30℃

Compare Remove

Air Jacketed CO2 Incubator LAJI-C20

CO₂ range : 0-20%
CO₂ recovery time : (Return to 5% after opening the door for 30 seconds) ≤3 mins
CO₂ control accuracy : ±0.1%
CO₂ stability of 5%CO₂ : ±0.1%

Compare Remove

Air-jacketed CO2 Incubator:
Air Jacketed CO₂ Incubator LAJI-D10, Air Jacketed CO2 Incubator LAJI-B11, Air Jacketed CO2 Incubator LAJI-C12, Air-Jacketed CO₂ Incubator LAJI-E11, Air Jacketed CO2 Incubator LAJI-B16, Air Jacketed CO2 Incubator LAJI-B18, Air Jacketed CO2 Incubator With UV Sterilization LAJI-F22, Air Jacketed CO₂ Incubator LAJI-C20, and more.
