info@labtron.com.webp "ICP Optical Emission Spectrometer LICP-C11")
| Wavelength Range | 160 to 1000 nm |
| Grating | Middle step grating, 52.67 lp/mm, 64° sparkle angle |
| Numerical Aperture | F < 8, ultra-high luminous flux |
| Target Size | 27.6 mm x 27.6 mm, 1024 x 1024 addressing detection units |
| Resolution | < 0.0065 nm at 200 nm |
| Astigmatism | Equivalent background concentration of 10000 ppm Ca solution at As 189.042 nm < 2 ppm |
| Light Chamber | Precision constant temperature, 35 ± 0.1°C, nitrogen purging (normal: 1.8 L/min, fast: 3.8 L/min) |
| Plasma Argon Flowmeter | 100 to 1000 L/h (1.6 to 16 L/min) |
| Auxiliary Argon Flowmeter | 100 to 1000 L/h (0.16 to 1.6 L/min) |
| Auxiliary Carrier Argon Flowmeter | 100 to 1000 L/h (0.16 to 1.6 L/min) |
| Pressure Maintaining Value | 0 to 0.4 MPa |
| Cooling Water Temperature | 20 to 25°C |
| Cooling Water Flow Rate | > 5 L/min |
| Cooling Water Hydraulic Pressure | > 0.1 MPa |
| Output Working Coil Inner Diameter | 25 mm |
| Torque Tube | Three concentric, external diameter 20 mm |
| Coaxial Nebulizer | Outer diameter 6 mm |
| Double Barrel Atomizing Chamber | Outer diameter 34 mm |
| Circuit Type | Solid-state RF Power supply, with auto match function |
| Frequency | 27.12 MHz ± 0.05% |
| Frequency Stability | < 0.1% |
| Power Output Stability | < 0.3% |
| Escaped RF Radiation | 30 cm away from instrument, Electric Field: E < 2 V/m |
| Power Consumption | 800 to 1500 W |
| Power Supply | 220V, 30A |
| Dimension | 1050 × 793 × 745mm |
| Packaging Dimension | 1250 × 950 × 900 mm |
| Weight | 105 Kg |
| Gross Weight | 120Kg |
ICP Optical Emission Spectrometer LICP-C11 is used to analyze trace elements in substances soluble in nitric, hydrochloric, and hydrofluoric acids, in fields like environmental protection, petroleum, rare earths, semiconductors, geology, metallurgy, clinical medicine, food safety, forensics, and agriculture.
Cable × 1 line
Plastic drum × 1 pcs
Argon Gas Reduction × 2 pcs
PU tube 30 m × 1 pcs
PU tube 10 m × 1 pcs
PVC transparent tube × 1 meter
Plug × 1 pcs
Ground copper braided wire × 15 lines
Brass tube × 1 pcs
Filter element of filter tank × 4 pcs
Capillary tube × 0.5 meter
Torch pipe × 2 pcs
Double cylinder fog chamber × 2 pcs
Atomizer × 1 pcs
Pump head hose of Peristaltic Pump (Ф1.65 L45cm) × 3 line
Electronic Fuses(10A,250V,6×30mm) × 2 line
Electronic Fuses (6.3A,250V,5×20mm) × 2 line
Cylindric atomizer × 2 pcs
Silicone tube (Inner 2mm, outer 4mm, hardness:55HRC) × 0.3 meter
Hose adapter (ZCJH-2*6 INNER 6-2) × 4 pcs
Hose adapter (ZC-1/16*3/32 INNER 1.6-2.4) × 4 pcs
Spherical connector clamp- 1 pcs
O shape seal ring (32.5×3.55) × 2 pcs
O shape seal ring (5.6×1.8) × 4 pcs
Quick Connector(Φ6) × 2 pcs
Raw material belt (26mm×20m, thin:0.1~0.2mm) × 1 roll
Ribbon × 30 line
Toolkit- 1 set
Computer (Lenovo) × 1 set
Displayer (Lenovo) × 1 set
Canon Printer (Laser printer) × 1 set
Cooling water tank × 1 set
Automatic Sampler
Labtron ICP Spectrometer are designed for the detection and analysis of trace and ultra-trace elements. They use advanced argon plasma technology to efficiently measure multiple elements per minute. Each unit has a highly sensitive detection system with low detection limits, providing accurate results for both liquid and solid samples. Equipped with Czerny-Turner optical pathways, these spectrometer provide exceptional optical resolution and stability. They feature advanced control systems for improved signal-to-background ratios. Our ICP Spectrometer comes with dual verniers for error reduction and optical drain sensors for enhanced sensitivity and accuracy.
