| Force Measuring Range | 0 to 2 N (customizable) |
| Accuracy | 0.5 level |
| Sample Thickness | Up to 2 mm (customizable) |
| Coefficient Measurement Range | 0.001 to 0.999 |
| Slider Size | 63 × 63 mm |
| Test Speed | 0 to 300 mm (stepless speed change) |
| Slider Mass | 200 g (customizable) |
| Work Surface Size | 200 × 470 mm |
| Measurement Tolerance | ± 2% |
| Power Supply | AC 220 V, 50 Hz |
Large touchscreen display
Simple operation
Stepless test speed regulation
Longer lifespan and better performance
Stable performance and accurate test results
Our Coefficient of Friction Tester LCOFT-A11 is used in industries like packaging, paper, and film manufacturing to measure the static and dynamic friction coefficients of materials such as plastic films, rubber, cardboard, and coatings. It helps assess material smoothness, opening difficulty, and uniformity, ensuring quality control in production.
Micro printer × 1
Slider × 1
Data line × 1
Power cord × 1
Download catalog for
Coefficient Of Friction Tester LCOFT-A11 Catalog
Labtron Paper Testing Instruments requires air supply for automatic clamping, ensuring smooth and secure operation. These provide real-time pressure curve displays, allowing users to monitor pressure changes instantly. Their over-range reset function protects the sensor by automatically adjusting it in case of excessive readings. They measure ink absorption values, useful for quality control in printing processes. Our paper testing instruments measure WH Hunter whiteness, YI yellowness, and CIE whiteness for precise color and whiteness evaluations for various applications.
.webp "Paper and cardboard thickness meter TP-E21")
.webp "Electronic Tearing tester TP-J21")
Labtron’s Coefficient of Friction Tester is designed to measure the static and dynamic friction coefficients of various materials such as plastic films, rubber, paper, cardboard, woven bags, wood, and coatings. It helps manufacturers assess the smoothness, opening difficulty, and uniformity of materials, ensuring better quality control in industries like packaging, paper manufacturing, and film production. By accurately determining friction properties, it enables companies to optimize production processes and maintain product standards.
Our Coefficient of Friction Tester operates by cutting a sample into two pieces, with one placed on the worktable and the other on a slider. The slider is placed on the sensor hanging hole, allowing it to move under the influence of gravity. As the two surfaces move relative to each other, a sensor measures the force exerted, which is then processed to determine the static and dynamic friction coefficients. The collected data is displayed on a touchscreen and can be printed for further analysis.
The Coefficient of Friction Tester can be used to test a wide range of materials, including plastic films, plastic rubber, paper, cardboard, woven bags, wood, and coatings. These materials are commonly used in industries where friction properties are critical for packaging, printing, or surface treatment processes. The tester helps in evaluating material behavior under different conditions to ensure quality and performance consistency.
Our Coefficient of Friction Tester provides highly accurate results with a measurement tolerance of ±2% and an accuracy level of 0.5. This level of precision ensures that manufacturers receive reliable data for quality control, material selection, and production process improvements. The device’s sensitive sensor and advanced data processing system contribute to its accuracy and repeatability.
Yes, our Coefficient of Friction Tester complies with several international testing standards, including GB 10006, ISO 8295, ASTM D1894, and TAPPI T81. These standards ensure that the device provides reliable and standardized test results that meet global industry requirements.
