Izod Impact Tester LZIT-A10

The Izod Impact Tester LZIT-A10 is designed to measure the impact strength of a wide range of non-metallic materials. This includes engineering plastics, fiberglass-reinforced plastics, ceramics, cast stone, electrical insulation materials, and plastic pipes. By applying a controlled impact at a specified angle with a defined weight, the tester measures the energy absorbed by the specimen, helping to assess its toughness and resistance to sudden mechanical forces. This makes it ideal for laboratories and production environments where material durability and performance testing are critical.

The Izod Impact Tester LZIT-A10 complies with major international testing standards, including ISO180, ASTM D256, JB8762, JB8761, and ISO9854 cantilever beam (Izod) standards. Compliance ensures that all test results are consistent, reliable, and accepted in quality control and research applications globally. This allows users to confidently perform material testing for regulatory requirements and internal quality assurance, making it suitable for industrial, laboratory, and educational purposes.

The Izod Impact Tester LZIT-A10 incorporates multiple safety features to protect operators during testing. It includes a safety baffle to shield users from broken specimen fragments, and the impact action is controlled by a button to prevent accidental release. Additionally, the collecting hopper captures broken specimens automatically after the test, minimizing manual handling. These features, combined with its compact design, ensure that testing can be conducted safely and efficiently in both laboratory and production environments.

The Izod Impact Tester LZIT-A10 offers a clear angle display with 1° resolution, enabling precise measurement of the impact angle for each test. It supports selectable impact energies ranging from 1J to 22J, with standard values of 1J, 2.75J, and 5.5J, and optional 11J and 22J for more demanding applications. The impact velocity is 3.46 m/s with a drop angle of 150°, ensuring compliance with international standards. Its compact footprint allows for easy integration into laboratories and production lines, making it both versatile and user-friendly.

The Izod Impact Tester LZIT-A10 is suitable for a wide range of applications where determining the toughness of non-metallic materials is critical. It is commonly used in quality control, research and development, material certification, and industrial testing for plastics, fiberglass, ceramics, insulating materials, and composite materials. By measuring the energy absorbed during impact, it helps manufacturers, engineers, and researchers evaluate material performance, predict failure points, and improve product design, ensuring reliability and safety in real-world applications.
