The Stainless-Steel Glove Box LSSG-C10 features a main chamber with a capacity of 600 × 450 × 420 mm, providing a spacious workspace. It has an antechamber which separates the main chamber and allows safely transfer of materials. Its thickness of the chamber wall is 6 mm, which allows enduring high-pressure and vacuum pressures. Additionally, it is tempered glass of a thickness of 10 mm to ensure safety and pressure endurance. Our Glove box can be used in organic metal chemistry, organic synthesis, etc.
| Chamber Dimensions | 600 × 450 × 420 mm |
| Thickness | 6 mm |
| Vacuum Degree | -0.1 M Pa |
| Pressure | ± 1000 PA |
| Antechamber | Φ 210 × 260 L |
| Side Door Dimensions | 300 × 260 mm |
| Window Material Thickness | Front of the main chamber has thickness of 10 mm made with tempered glass material |
| Ball valve | Stainless steel ball valve, quick plug or pagoda head interface, one inlet and one outlet respectively |
| Lights | White light pre-installed (on the upper part of each glass window) |
| Chamber Power sockets | Multi-hole power sockets |
| Gloves | One pair of latex gloves with length 600mm |
| Reserved interface | Reserved interface for KF 25 ( can be upgraded as per requirement in the future) |
Thick stainless steel sheet
Low leakage rate
Internal power sockets
Customizable system settings
User-friendly operation
Stainless Steel Glove Box LSSG-C10 is built from high-quality stainless-steel sheet, making it durable to high pressure, making it ideal for research and production of sensitive materials. Our glove box is ideal for Our Glove box can be used for organic synthesis, 3D printing, etc.
1 | 2 L Vacuum Pump |
2 | 4 L Vacuum Pump |
3 | Movable bracket |
4 | Fully automatic pressure controller |
5 | Imported moisture sensor |
6 | Imported oxygen sensor |
7 | Fully automatic moisture controller |
8 | Fully automatic oxygen controller |
9 | Foot pressure controller |
10 | UV sterilization lamp |
11 | Dust removal and cleaning system |
12 | Purification system H2O & O2 ≤ 0.1 PPM |
Stainless Steel Glove Boxes are laboratory equipment that can maintain a highly purified, anhydrous, and inert environment for research and experimentation. These use the mechanism of multiple vacuum extractions to replace the gases. The main chamber is non-corrosive stainless steel, which is of the thickness of 3 mm. Additionally, these boxes have reinforced ribs outer shell for better pressure tolerance. Our Glove box is mainly used for creating anaerobic and non-humid environments for organic metal chemistry, etc.
Yes, the A-series glove box can be integrated with a variety of lab instruments such as balances, microscopes, or analytical tools. Feed through ports or cable pass-through allow instrument connectivity while maintaining environmental integrity. Custom mounts or internal platforms can be designed to accommodate specific devices safely.
The glove box is equipped with a high-quality polycarbonate or tempered glass viewing window that offers excellent optical clarity and impact resistance. It is scratch-resistant to a good extent but may require occasional cleaning with non-abrasive materials to maintain clear visibility. Protective films can also be applied if scratch sensitivity is a concern.
Safety features include air-tight gaskets, pressure relief valves, and interlocking doors for antechambers, glove port seals, and optional HEPA/ULPA filtration. Some models also include alarms for over/under pressure, low gas flow, or glove leakage. These ensure the operator’s safety and prevent contamination or environmental leaks.
Depending on the configuration, the A-series may include internal circulation fans or gas purification systems that maintain uniform conditions inside. For inert gas models, gas is circulated and purified through moisture and oxygen removal cartridges. Efficient circulation ensures uniform atmosphere and reduces gas consumption during purging.
Delivery time typically ranges from 2 to 6 weeks, depending on customization and availability. Installation is straightforward and includes positioning the unit, connecting gas lines, testing glove integrity, and ensuring all seals and ports are functioning. Some models require power for integrated systems; basic training is provided to familiarize operators with operation and maintenance.
