Temperature and Humidity Test Chamber LTHC-A12

Temperature and Humidity Test Chamber LTHC-A12

Temperature and Humidity Test Chamber LTTC-A12 has a 250 L capacity and a temperature range of -20°C to +150°C. Its heating system includes independent NiCr heaters for fast heat-up. It includes a robust, high-temperature resistant fan for uniform air circulation. The chamber is equipped with automatic water supply and shortage alarm for humidification. Our temperature and humidity test chamber provides high performance and cost-effective solutions for product testing.
Temperature and Humidity Test Chamber LTHC-A12-1
Temperature and Humidity Test Chamber LTHC-A12-2
Temperature and Humidity Test Chamber LTHC-A12-3
Temperature and Humidity Test Chamber LTHC-A12-4
Temperature and Humidity Test Chamber LTHC-A12-5
Request Quote
Capacity 250 L
Temperature Range -20°C to +150°C, -40°C to +150°C, -70°C to +150°C
Temperature Fluctuation ≤±0.5°C
Temperature Uniformity ≤2°C
Heating Rate 2.0 to 3.0°C/min
Cooling Rate 0.7 to1.0°C/min
Humidity Range 20% to 98% R.H
Humidity Bias +2/-3% R.H
Shelf 2 pcs
Color Blue
Insulation Superfine fiberglass wool / polyurethane foam
Controller 7-inch controller
Circulation System High temperature resistant motors, single cycle, long axis and stainless-steel multi-leaf type centrifuge fan
Humidification Shallow groove humidification, steam humidification mode, automatic water supply with water shortage alarm
Dehumidification Refrigeration dehumidification mode
Refrigeration "TECUMSEH" Hermetic Compressors, Unit cooling mode/Dual cooling mode (air-cooling), Refrigerant R404 A/R23
Protection Leakage and outage protection, compressor over-pressure, overheat, over-current protection, overload fusing protection, audio signal alarm, water shortage alarm
Exterior Material Cold rolled steel plate with electrostatic spraying
Power Supply 220V 50HZ/60HZ,380V 50HZ/60HZ
Interior Dimension 600 × 500 × 810 mm
Exterior Dimension 1120 × 1100 × 2010 mm
Net Weight 450 Kg
Gross Weight 550 Kg
  • LCD touch screen
  • Multiple protection systems
  • Anti-corrosion stainless steel
  • Spacious interior with ample shelving
  • High-quality refrigerator systems
Our Temperature and Humidity Test Chamber LTTC-A12 is used in industries where testing under varying environmental conditions is crucial. It is ideal for electronics, automotive, aerospace, telecommunications, packaging, and chemicals.
