Temperature and Humidity Test Chamber LTHC-C20

Temperature and Humidity Test Chamber LTHC-C20

Temperature and Humidity Test Chamber LTHC-C20 is a Constant Temperature & Humidity Chamber comes with 150 L of capacity. Equipped with LCD display, microprocessor controller for temperature and humidity, imported condenser and independent temperature-limiting alarm system, this device provides temperature range of 10 to 70°C with 0.1°C resolution. Designed with polished stainless steel chamber having 3 adjustable shelves, comprising semi-circular arcs at corner for easy cleaning and maintenance. This device have 25mm instruction connection hole on the left side of the chamber for easy testing operation and temperature measurement.

Request Quote
Capacity 150 L
Temperature range 10 to 70°C
Temperature stability High: ±0.5℃; Low: ±1℃
Temperature uniformity ±2°C
Display resolution 0.1°C
Ambient temperature +5 to 35°C
Humidity range 40 to 95%
Humidity accuracy ±3% RH
Material Stainless steel
Shelves 3 pcs
Controller Microprocessor
Display LCD
Connection hole 25 mm
Condenser 1 pc
Alarm system Independent temperature-limiting alarm system
Power supply 220 V/50 Hz
Power 2100 W
Internal dimensions (W×D×H) 550×405×670 mm
External dimensions (W×D×H) 690×800×1430 mm
Net weight 186 kg
Gross weight 216 kg
  • Constant Temperature & Humidity Chamber with 150 L of capacity
  • LCD display with 0.1°C of display resolution
  • Microprocessor controller for temperature and humidity, ensures precise and reliable control
  • Imported condenser and independent temperature-limiting alarm system
  • Polished stainless steel chamber with 3 adjustable shelves
  • Semi-circular arcs at corner for easy cleaning and maintenance
  • 25mm instruction connection hole on the left side of the chamber for easy testing operation and temperature measurement
  • Printer connector and RS485 connector as options
  • Precise and reliable control with timing function

Temperature and Humidity Test Chamber are used in sterile tests and stability check-up of pharmaceuticals, textile and food processing as well as tests in material, performance, packing and lifetime of industrial products.

Printer
Independent temperature-limiting Alarm system
Rs485

Compare Models

Model Capacity Temperature range Temperature stability Temperature uniformity Display resolution Ambient temperature Humidity range Humidity accuracy Material Shelves Controller Display Connection hole Condenser Alarm system Power supply Power Internal dimensions (W×D×H) External dimensions (W×D×H) Net weight Gross weight
LTHC-A10 50 L (- 20 °C) to 150 °C - - - - 20 % - 98 % RH - - - - - - - - AC 220 , 50 Hz - - - - -
LTHC-A11 80 L (- 20 °C) to 150 °C - - - - 20 % - 98 % RH - - - - - - - - AC 220 , 50 Hz - - - - -
LTHC-B10 100 L (-20)℃ to 150 ℃ ,(-40) ℃ to 150 ℃ , (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B11 225 L (-20)℃ to 150 ℃ ,(-40) ℃ to 150 ℃ , (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B12 500 L (-20)℃ to 150 ℃ ,(-40) ℃ to 150 ℃ , (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B13 800 L (-20)℃ to 150 ℃ ,(-40) ℃ to 150 ℃ , (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B14 1000 L (-20)℃ to 150 ℃ ,(-40) ℃ to 150 ℃ , (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B20 100 L (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B21 225 L (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B22 500 L (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B23 800 L (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B24 1000 L (-70 )℃ to 150 ℃ - - - - 20 % ~ 98 % R.H - - - - - - - - - - - - - -
LTHC-B30 3150 L -40℃ to 150℃ - - - - 10% to 98% RH - - - - PID Touch color LCD screen controller - - - 380 V, 50 Hz - - - - -
LTHC-C10 - - - - - - - - - - Programmable color LCD touch screen controller Ethernet connection, PC Link - - - - - - - - - -
LTHC-C20 150 L 10 to 70°C High: ±0.5℃; Low: ±1℃ ±2°C 0.1°C +5 to 35°C 40 to 95% ±3% RH Stainless steel 3 pcs Microprocessor LCD 25 mm 1 pc Independent temperature-limiting alarm system 220 V/50 Hz 2100 W 550×405×670 mm 690×800×1430 mm 186 kg 216 kg
LTHC-B25 1500 L (-60) ℃ to +150 ℃ - - - - 10% to 98% RH - - - Programmable color LCD touch screen controller - - - - - - - - - -
LTHC-C30 550L - - - - - - - - - - Standard TATO 7" LCD touchscreen - - - - - - - - -
