Temperature and Humidity Test Chamber LTHC-C20 is a Constant Temperature & Humidity Chamber comes with 150 L of capacity. Equipped with LCD display, microprocessor controller for temperature and humidity, imported condenser and independent temperature-limiting alarm system, this device provides temperature range of 10 to 70°C with 0.1°C resolution. Designed with polished stainless steel chamber having 3 adjustable shelves, comprising semi-circular arcs at corner for easy cleaning and maintenance. This device have 25mm instruction connection hole on the left side of the chamber for easy testing operation and temperature measurement.
Capacity | 150 L |
Temperature range | 10 to 70°C |
Temperature stability | High: ±0.5℃; Low: ±1℃ |
Temperature uniformity | ±2°C |
Display resolution | 0.1°C |
Ambient temperature | +5 to 35°C |
Humidity range | 40 to 95% |
Humidity accuracy | ±3% RH |
Material | Stainless steel |
Shelves | 3 pcs |
Controller | Microprocessor |
Display | LCD |
Connection hole | 25 mm |
Condenser | 1 pc |
Alarm system | Independent temperature-limiting alarm system |
Power supply | 220 V/50 Hz |
Power | 2100 W |
Internal dimensions (W×D×H) | 550×405×670 mm |
External dimensions (W×D×H) | 690×800×1430 mm |
Net weight | 186 kg |
Gross weight | 216 kg |
Temperature and Humidity Test Chamber are used in sterile tests and stability check-up of pharmaceuticals, textile and food processing as well as tests in material, performance, packing and lifetime of industrial products.
Printer
Independent temperature-limiting Alarm system
Rs485
Download catalog for
Temperature and Humidity Test Chamber LTHC-C20 Catalog
Available Range :
Temperature and Humidity Test Chamber LTHC-B10 : 100 L Temperature and Humidity Test Chamber LTHC-B14 : 1000 L Temperature And Humidity Test Chamber LTHC-E11 : 105 L Temperature and Humidity Test Chamber LTHC-D11 : 1130L Temperature And Humidity Test Chamber LTHC-A14 : 120L Temperature and Humidity Test Chamber LTHC-C20 : 150 L Temperature and Humidity Test Chamber LTHC-B25 : 1500 L Temperature and Humidity Test Chamber LTHC-B11 : 225 L Temperature And Humidity Test Chamber LTHC-A15 : 225L Temperature and Humidity Test Chamber LTHC-A12 : 250 L Temperature and Humidity Test Chamber LTHC-D10 : 300L Temperature and Humidity Test Chamber LTHC-B30 : 3150 L Temperature And Humidity Test Chamber LTHC-E13 : 408 L Temperature And Humidity Test Chamber LTHC-A10 : 50 L Temperature and Humidity Test Chamber LTHC-B12 : 500 L Temperature And Humidity Test Chamber LTHC-A16 : 504L Temperature and Humidity Test Chamber LTHC-C30 : 550L Temperature And Humidity Test Chamber LTHC-A13 : 64 L Temperature And Humidity Test Chamber LTHC-A11 : 80 L Temperature and Humidity Test Chamber LTHC-B13 : 800 L Temperature And Humidity Chamber LTHC-G10 : Total of 500L Temperature And Humidity Chamber LTHC-G11 : Total of 800LLabtron offers temperature and humidity test chambers with capacities ranging from 50 to 1130 L. They have a humidity controller and thermal-insulating material resistant to high temperatures. They feature an LCD touch screen with a corrosion-resistant interior chamber and a double-layered glass observation window. They include an independent R&D software and a compressor overload switch. Our temperature and humidity tester has built-in safety self-protection and overheating prevention.
