System | Cascade |
Capacity | 408 L |
Temperature Range | -40℃ to -86℃ |
Ambient Temperature | 10℃ to 32℃ |
Refrigerant | HC (R290 and R170) |
Sensor | PTC |
Compressor | 2 |
Cooling Type | Direct Cooling |
Defrost | Manual |
Insulation | PURF |
Noise | 50 dB |
Compartment | 4 |
Inner door | 2 |
Racks | 8 (5 × 4) × 8 (4 × 4) |
Boxes (2 Inch) | 288 |
Samples (2 ml) | 28800 |
Exterior material | Color Sprayed Steel |
Interior material | Stainless steel |
Remote Alarm Access | Yes |
RS 485 Access | Yes |
Alarms | High/low temperature Power failure Abnormal voltage Sensor error Door ajar Filter screen check Thermostat failure Low battery Condenser clean High ambient temperature 72 hr Power failure backup |
Current | 8.95 A |
Power | 650 W |
Power consumption | 12.43 Wh/24h |
Power Supply | 220V/50Hz |
Exterior Dimension | 891 × 992 × 1945.5 mm |
Interior Dimension | 606 × 575 × 1180 mm |
Package Dimension | 954 × 955 × 2094 mm |
Net Weight | 292 Kg |
Gross Weight | 317 Kg |
Download catalog for
-86 °C Ultra Low-Temperature Upright Freezer LUF-F11 Catalog
Available Range :
-86 °C Ultra Low-Temperature Upright Freezer LUF-F14 : Cascade -86 °C Ultra Low-Temperature Upright Freezer LUF-C10 : Dual System -86 °C Ultra Low Temperature Upright Freezer LUF-C13 : Sensor error, Built-in data logger USB failure , Main board communication error , Condenser cooling failure, Door ajar, Samples out of date, System failure -86 °C Ultra Low Temperature Upright Freezer LUF-C14 : Sensor error, Built-in data logger USB failure ,Main board communication error , System failure, Condenser cooling failure ,Door ajar, Samples out of date -86 °C Ultra Low Temperature Upright Freezer LUF-D20 : Sensor error, Main board communication error ,System failure, Condenser cooling failure, Door ajar, Samples out of date -86 °C Ultra Low Temperature Upright Freezer LUF-C11 : Sensor error, Main board communication error, Built-in data logger USB failure, Condenser cooling failure, Door ajar, Samples out of date, System failure -86 °C Ultra Low Temperature Upright Freezer LUF-D21 : Sensor error, System failure, Condenser cooling failure, Door ajarSimilar Products
