| Sterilization Method | UV sterilization |
| Capacity | 180 L |
| Temperature Range | RT+5 to 55℃ |
| Ambient temperature range | 18 to 30℃ |
| Temperature Fluctuation | ±0.3℃ |
| Temperature Uniformity | ±0.5℃ |
| Temperature Control Accuracy | ±0.1°C |
| Relative Humidity | Greater than 90% |
| CO2 Inlet Pressure | 0.05 to 0.1 MPa |
| CO2 Control Range | 0 to 20 %vol |
| CO2 Control Accuracy | ±0.1 %vol |
| CO2 Recovery Time | 6 min (at 5% vol) |
| CO2 Intake Time | 5 min (at 5% vol) |
| CO2 Fluctuation | ±0.1% vol |
| Amount of Water Required | 3.0 L |
| Standard Quantity of Shelves | 3 |
| Maximum Quantity of Shelves | 18 |
| Power Consumption | 950 W |
| Power Supply | AC 220V (± 10%) 50/60Hz |
| Shelve Dimensions | 450 × 465 mm |
| Internal Dimensions (W x D x H) | 500 × 520 ×700 mm |
| Housing Dimensions (W x D x H) | 750 × 740 × 1060 mm |
| Load per Shelf | 10 Kg |
Our Air Jacketed CO2 Incubator with UV Sterilization is ideal for quality control labs in biotechnology sectors, offering a contamination-free environment for cell-based assays, validation, and testing under documented conditions.
Download catalog for
Air Jacketed CO2 Incubator With UV Sterilization LAJI-F21 Catalog
Available Range :
Air Jacketed CO2 Incubator LAJI-A10 : 18hrs (90°C moist heat disinfection) Air Jacketed CO2 Incubator LAJI-A11 : 90°C moist heat disinfection Air Jacketed CO2 Incubator LAJI-C21 : 90˚ C moist heat sterilization Air Jacketed CO2 Incubator LAJI-B16 : Dry Heat Sterilization Air Jacketed CO2 Incubator With Moist Heat Sterilization LAJI-F10 : Moist heat sterilization Air Jacketed CO₂ Incubator LAJI-B13 : Ultraviolet Sterilization Air Jacketed CO2 Incubator LAJI-B10 : UV Lamp disinfection Air Jacketed CO2 Incubator With UV Sterilization LAJI-F20 : UV sterilization
Labtron Air-Jacketed CO2 Incubator is specialized to maintain optimal condition with chamber volume of 40 L to 570 L. Their dual-layer construction ensures stable internal temperature and protects against external fluctuations effectively. They are equipped with carbon dioxide monitoring system to measure accurate gas concentration levels. Their humidity control system prevents dehydration of cell cultures, promoting healthy growth environments consistently. Our Air-Jacketed CO2 Incubator culture sensitive cells and tissues for stem cell research and genetic engineering.
The Air Jacketed CO2 Incubator with UV Sterilization LAJI-F21 is primarily used in biotechnology, pharmaceutical, and research laboratories for high-precision cell culture applications. Its 180-litre capacity supports high-throughput workflows, making it suitable for cell-based assays, tissue culture, genetic studies, and drug development. The contamination-free environment created by its UV sterilization system makes it ideal for sensitive cultures. It also meets the environmental stability requirements for long-term experiments, ensuring reproducibility and compliance with laboratory standards.
The Air Jacketed CO2 Incubator with UV Sterilization LAJI-F21 CO2 incubator includes an integrated UV sterilization system that effectively deactivates airborne microorganisms and contaminants inside the chamber. This continuous sterilization process helps prevent cross-contamination between cultures, even during extended experimental periods. Additionally, the mirror-finish inner chamber with rounded corners allows easy cleaning, reducing the chances of residue buildup. These design elements work together to maintain a sterile environment, which is essential for sensitive biological samples and long-duration research.
The Air Jacketed CO2 Incubator with UV Sterilization LAJI-F21 features a spacious 180-litre chamber that accommodates up to 18 shelves, making it ideal for high-throughput environments where multiple samples are processed simultaneously. Its uniform heating system ensures consistent temperature distribution across all shelves, while the advanced data and event management systems allow seamless tracking of operational performance. The incubator also includes user access control, low water level alarms, and CO2 regulation with high accuracy, supporting both efficiency and reliability in busy lab settings.
The Air Jacketed CO2 Incubator LAJI-F21 with UV Sterilization model includes multiple safety features designed to protect both users and samples. It comes with an independent adjustable temperature limit switch to prevent overheating, a water level sensor that alerts users to refill when needed, and a magnetic door switch to reduce parameter fluctuations when the door is opened. The event management system logs all actions and errors with timestamps for traceability, while USB and 485 interfaces ensure secure data backup and monitoring. These features collectively enhance operational safety and regulatory compliance.
The Air Jacketed CO2 Incubator with UV Sterilization LAJI-F21 includes a comprehensive data management system that can store over 500,000 records. Users can view performance data and real-time curves directly on the 7-inch HD touch screen or export them using a USB drive in an unchangeable format for documentation and auditing. This capability allows labs to maintain accurate records for compliance, monitor trends, and trace events related to environmental control. The system also includes multi-user access control, ensuring that all operations are securely logged and managed.
