| Sterilization Method | Moist heat sterilization |
| Capacity | 180 L |
| Temperature Range | RT+5 to 55℃ |
| Ambient temperature range | 18 to 30℃ |
| Temperature Fluctuation | ±0.3℃ |
| Temperature Uniformity | ±0.5℃ |
| Temperature Control Accuracy | ±0.1°C |
| Relative Humidity | Greater than 90% |
| CO2 Inlet Pressure | 0.05 to 0.1 MPa |
| CO2 Control Range | 0 to 20 %vol |
| CO2 Control Accuracy | ±0.1 %vol |
| CO2 Recovery Time | 6 min (at 5% vol) |
| CO2 Intake Time | 5 min (at 5% vol) |
| CO2 Fluctuation | ±0.1% vol |
| Amount of Water Required | 3.0 L |
| Standard Quantity of Shelves | 3 |
| Maximum Quantity of Shelves | 18 |
| Power Consumption | 950 W |
| Power Supply | AC 220V (± 10%) 50/60Hz |
| Shelve Dimension | 450 × 465 mm |
| Internal Dimension (W x D x H) | 500 × 520 ×700 mm |
| Housing Dimension (W x D x H) | 750 × 740 × 1060 mm |
| Load per Shelf | 10 Kg |
| Net Weight | 98 Kg |
| Gross Weight | 138 Kg |
Our Air Jacketed CO2 Incubator with Moist Heat Sterilization is used in cell culture, tissue engineering, and microbiological research where stable CO2, high humidity, and accurate temperature regulation are critical.
Download catalog for
Air Jacketed CO2 Incubator With Moist Heat Sterilization LAJI-F11 Catalog
Available Range :
Air Jacketed CO2 Incubator LAJI-A10 : 18hrs (90°C moist heat disinfection) Air Jacketed CO2 Incubator LAJI-C21 : 90˚ C moist heat sterilization Air Jacketed CO2 Incubator LAJI-B16 : Dry Heat Sterilization Air Jacketed CO2 Incubator With Moist Heat Sterilization LAJI-F10 : Moist heat sterilization Air Jacketed CO₂ Incubator LAJI-B13 : Ultraviolet Sterilization Air Jacketed CO2 Incubator LAJI-B10 : UV Lamp disinfection Air Jacketed CO2 Incubator With UV Sterilization LAJI-F20 : UV sterilization
Labtron Air-Jacketed CO2 Incubator is specialized to maintain optimal condition with chamber volume of 40 L to 570 L. Their dual-layer construction ensures stable internal temperature and protects against external fluctuations effectively. They are equipped with carbon dioxide monitoring system to measure accurate gas concentration levels. Their humidity control system prevents dehydration of cell cultures, promoting healthy growth environments consistently. Our Air-Jacketed CO2 Incubator culture sensitive cells and tissues for stem cell research and genetic engineering.








The Air Jacketed CO2 Incubator with Moist Heat Sterilization LAJI-F11 model is ideal for a wide variety of laboratory applications that demand precise environmental control. It is particularly suited for cell culture, tissue engineering, and microbiological research. Its ability to maintain accurate CO2 levels, high humidity, and uniform temperature makes it excellent for cultivating mammalian cells, anaerobic bacteria, and stem cells. The incubator also supports applications in IVF, regenerative medicine, and pharmaceutical testing where sterile, stable conditions are critical. Overall, the LAJI-F11 meets the rigorous standards of research, clinical, and industrial labs.
The Air Jacketed CO2 Incubator with Moist Heat Sterilization LAJI-F11 uses a multi-zone direct hot gas jacket heating system that ensures fast and uniform temperature distribution. It features eight heating units across three independent temperature zones, eliminating cold spots and preventing condensation inside the chamber. For CO2 control, the unit employs an imported dual-wavelength IR sensor that delivers high-accuracy readings with zero drift. The incubator quickly stabilizes CO2 levels, with recovery times as fast as 6 minutes after a door opening. These features ensure that all areas inside the chamber maintain consistent environmental conditions, essential for reproducible results.
The Air Jacketed CO2 Incubator with Moist Heat Sterilization LAJI-F11 maintains tightly regulated CO2 levels (±0.1% vol), precise temperature control (±0.1°C), and high relative humidity (above 90%), all of which are crucial for long-term culture of sensitive cell lines. The multi-zone heating system prevents localized hotspots or cold zones, while the high-efficiency IR CO2 sensor ensures stable gas concentration throughout extended incubation periods. The mirror-finish stainless steel interior minimizes contamination risk and simplifies cleaning. These features together enable the LAJI-F11 to sustain optimal culture conditions over days or even weeks without environmental disruption.
The Air Jacketed CO2 Incubator with Moist Heat Sterilization LAJI-F11 is equipped with an advanced event management system that records all operational activities and alarms with exact timestamps. This includes door openings, sterilization cycles, parameter changes, and power interruptions. These logs are stored securely and can be exported in a tamper-proof format via USB for documentation or audit purposes. This functionality is particularly valuable in regulated environments such as pharmaceutical research or GMP-compliant labs where traceability is critical. It ensures complete transparency of incubator operations and supports internal and external quality audits.
The Air Jacketed CO2 Incubator with Moist Heat Sterilization LAJI-F11 is designed with built-in safeguards to handle unexpected power issues. It includes a memory retention function that preserves critical settings such as temperature, CO2 levels, and event logs during power outages. Once power is restored, the system resumes operation using the last saved parameters. This minimizes disruption to ongoing incubation processes and protects valuable samples from environmental instability. Additionally, alarms are triggered and logged to inform users of any interruptions, maintaining full transparency in lab conditions.
