Dual Disc Grinding and Polishing Machine LGPM-C10

Name: Dual Disc Grinding and Polishing Machine LGPM-C10
Brand: Labtron
SKU: LGPM-C10
Rating: 4.7 (939 reviews)

Dual Disc Grinding and Polishing Machine LGPM-C10 includes dual grinding discs with a standard 230 mm millstone diameter. Its independent motors provide precise operation and individual control for each disc. Speeds ranging from 100 to 1000 rpm can be adjusted independently for flexibility. With 8 gears, the machine allows user-defined settings for seamless speed regulation. A rotating water pipe enables directional adjustments and controlled water flow, making it ideal for sample preparation in metallographic analysis.

Request Quote

Disc Diameter	230 mm (Optional 203 mm)
Number of Grinding Discs	2
Speed Range	100 to 1000 rpm
Operation Mode	Dual motor
Rotation Direction	Anticlockwise / Clockwise
Motor Power	0.75 kW × 2
Power Supply	AC 220V, 50Hz
Dimension (L × W × H)	670 × 710 × 340 mm
Weight	52 kg

LED display for easy monitoring
Low noise operation
Anticlockwise/clockwise rotation
One-key switch for convenience
Independent motors for accurate control

Our Dual Disc Grinding and Polishing Machine LGPM-C10 is designed for material preparation, with adjustable speed and rotation for efficient polishing in research, quality control, manufacturing, and industrial environments.

Download catalog for
Dual Disc Grinding and Polishing Machine LGPM-C10 Catalog

Available Range :

Grinding and Polishing Machine LGPM-A10 : 203 mm /254 mm Dual Disc Grinding and Polishing Machine LGPM-C10 : 230 mm (Optional 203 mm) Dual Disc Grinding and Polishing Machine LGPM-C11 : 254 mm (Optional 200 mm, 230 mm, 300 mm) Grinding and Polishing Machine LGPM-A11 : φ230mm (standard), φ200mm (optional) Dual Disc Grinding and Polishing Machine LGPM-C12 : Φ254 mm (optional: Φ200, Φ230, Φ300)

Dual Disc Grinding and Polishing Machine LGPM-C10 | Disc Diameter 230 mm (Optional 203 mm) | Number of Grinding Discs 2

Dual Disc Grinding and Polishing Machine LGPM-C10 | LED display for easy monitoring | Low noise operation | Anticlockwise/clockwise rotation

Models of Grinding and Polishing Machine

Labtron Grinding and Polishing Machine offers modes for both grinding and polishing, with options for coarse and fine abrasives. They feature variable speed settings to adjust the rotation of the abrasive wheels. Their advanced control systems ensure precise operation, supported by digital displays and sensors for accuracy. A servo motor maintains high torque at all speeds for consistent performance of our grinding and polishing machine.
