Oil Pressure Filter LOPF-A12

Name: Oil Pressure Filter LOPF-A12
Brand: Labtron
SKU: LOPF-A12
Rating: 5 (706 reviews)

Oil Pressure Filter LOPF-A12 operates at a flow rate of 100 L/min, ensuring efficient purity and system efficiency. It includes integrated pressure monitoring, enabling easy tracking of pressure levels for optimal performance. The multi-layer filtration removes fine particles, sludge, and moisture for superior oil purity. Our Oil Pressure Filter efficiently removes impurities, ensuring clean oil for industrial use.

Request Quote

Flow Rate	100 L/min
Working Pressure	0 to 0.5 MPa
Filtering Area	Greater than or equal to 1.3 m²
Filter Room Number	10
Filter Plate Number	11
Oil Pump Pressure	0.6 Mpa
Filter Accuracy	Greater than or equal to 1µ
Filter Paper Size	285 × 290 mm
Motor Revolution	1400 r/min
Pipe Diameter Inlet	44 mm
Pipe Diameter Outlet	32 mm
Power Consumption	3000 W
Power Supply	380v 3Ph 50hz
Dimensions (L×W×H)	900 × 440 × 840 mm
Weight	130 kg

Optimized pressure regulation
Durable sealing mechanism
Minimal operational downtime
Enhanced dirt-holding capacity
Heavy-duty industrial motor

Oil Pressure Filter LOPF-A12 is used in life science industries to purify oils and fluids in laboratory equipment and biomanufacturing processes. It ensures the cleanliness of oils in machinery, reducing contamination risks in critical applications.

Download catalog for
Oil Pressure Filter LOPF-A12 Catalog

Available Range :

Oil Pressure Filter LOPF-A12 : 100 L/min Oil Pressure Filter LOPF-A13 : 150 L/min Oil Pressure Filter LOPF-A14 : 200 L/min Oil Pressure Filter LOPF-A10 : 30 L/min Oil Pressure Filter LOPF-A15 : 300 L/min Oil Pressure Filter LOPF-A11 : 50 L/min

Models of Oil Pressure Filter

Labtron Oil Pressure Filter utilizes mechanical pressure from a pinch device to ensure efficient oil flow through the filter media. They include a multi-stage filtration process to progressively remove impurities, ensuring superior oil purification and extended service life. These filters are available in high flow rate options, allowing efficient processing of large oil volumes. The leak-proof design ensures no oil escapes during operation, maintaining efficiency. Our Oil Pressure Filter removes impurities, water, and contaminants from oils, extending equipment life, improving performance, and ensuring clean operation in various industries.
