Vertical Autoclave LVA-P11

Vertical Autoclave LVA-P11

Vertical Autoclave LVA-P11 features chamber capacity of 50L for high-performance steam sterilization across laboratory and research settings. It offers a temperature range of 100 to 134°C, making it ideal for precise sterilization processes. This autoclave supports customizable sterilization and drying times, accommodating varied sterilization needs. Its compact design and standard power consumption make it efficient and ideal for use worldwide.

Request Quote
Chamber Capacity 50L
Control PID Processor
Display Digital Display
Material Fully Stainless Steel 304
Working Pressure 0.22 MPa
Working Temperature 134°C
Temperature Range 100 to 134°C
Sterilization Time Range 0 to 999 min
Drying Time Range 0 to 999 min (optional)
Temperature Accuracy ±0.1°C
Heat Distribution ≤1°C
Steam Generator Stainless Steel 304
Loading Capacity 1 pc Drum & 1 pc Basket
Casters With Brakes
Voltage 110 to 240V, 50/60Hz
Power Consumption 2.5 KW
Chamber Size 50L / Ø320 × 545 mm
Outer Dimensions 520 × 520 × 1000 mm
Packing Dimensions 570 × 570 × 1090 mm
Net Weight 55 kg
Gross Weight 75 kg
  • PID Control System
  • Digital Display
  • Stainless Steel Construction
  • Wide Temperature Range
  • Uniform Heat Distribution
  • Adjustable Sterilization & Drying Time
  • Stainless Steel Steam Generator
  • Efficient Loading Design
  • Mobility with Casters and Brakes
  • Global Voltage Compatibility
  • Energy Efficient Operation

Our Vertical Autoclave LVA-P11 is ideal for sterilizing a wide range of instruments and materials in laboratories, hospitals, research centers, and pharmaceutical settings.

  • Drying
Vertical Autoclave LVA-P11 | Material: Fully Stainless Steel 304 | Control: PID Processor
Vertical Autoclave LVA-P11 | Uniform Heat Distribution | Efficient Loading Design

Models of Vertical Autoclave

Labtron Vertical Autoclave provide upright design, high pressure steam sterilizer at working temperature of 134℃. Their orientation makes loading and unloading more convenient and efficient. They feature sensors and automatic shut off system enhancing safety by preventing overeating during operation. Their programmable controls enable automatic operation, managing heating, sterilization and cooling phases efficiently. Our Vertical Autoclave effectively eliminates pathogens from glassware and media, ensuring infection control in healthcare settings.

Vertical Autoclave LVA-A10

Vertical Autoclave LVA-A10

  • Capacity : 35 L
  • Maximum Working Pressure : 0.23 MPa
  • Working Pressure : 0.22 MPa
  • Working Temperature : 134°C
Vertical Autoclave LVA-B12

Vertical Autoclave LVA-B12

  • Capacity : 75 L
  • Working Pressure : 0.22 MPa
  • Working Temperature : 134°C
  • Temperature Range : 105 to 134°C
Vertical Laboratory Autoclave LVA-C14

Vertical Laboratory Autoclave LVA-C14

  • Capacity : 120 L
  • Sterilization Temperature : 134 °C
  • Sterilization Pressure : 0.22 Mpa
  • Chamber Dimension ( Φ × D ) : 480 × 660 mm
Vertical Autoclave LVA-O23
Vertical Autoclave LVA-O23
  • Capacity : 50 L
  • Chamber Volume : Φ350 × 550 mm
  • Chamber Thickness : 2.0 mm
  • Temperature Range : 50 °C to 126 °C
Vertical Laboratory Autoclave LVA-G11
Vertical Laboratory Autoclave LVA-G11
  • Capacity : 50L
  • Sterilization Temperature : 134 °C
  • Sterilization Pressure : 0.22 Mpa
  • Chamber Dimension ( Φ × D ) : 340 × 550 mm
Vertical Autoclave LVA-L10

Vertical Autoclave LVA-L10

  • Capacity : 60 L
  • Number of baskets : 2
  • Sterilization temperature : 105 °C to 138 °C
  • Working environment temperature : 5 °C to 45 °C
Vertical Autoclave LVA-H13

Vertical Autoclave LVA-H13

  • Capacity : 100 L
  • Working Pressure : 0 to 0.22 MPa
  • Working Temperature Range : 105 to 134°C
  • Sterilization Time : 0 to 99 min or 0 to 99 hour 59 min
Vertical Laboratory Autoclave LVA-I14

Vertical Laboratory Autoclave LVA-I14

  • Capacity : 120 L
  • Sterilization Temperature : 134 °C
  • Sterilization Pressure : 0.22 Mpa
  • Chamber Dimension ( Φ × D ) : 460 × 670 mm

Vertical Autoclave LVA-P11 FAQ's
  • The Vertical Autoclave LVA-P11 comes with a 50-liter chamber capacity, making it ideal for medium to large-volume sterilization. It can sterilize a wide range of materials such as surgical instruments, glassware, culture media, laboratory waste, textiles, and wrapped or unwrapped medical tools. Its spacious design supports both a drum and a basket, allowing efficient organization and sterilization of various load types.

  • The LVA-P11 features a PID processor-based control system and a digital display, which work together to ensure accurate temperature regulation with ±0.1°C precision. It operates in a temperature range of 100 to 134°C, and maintains uniform heat distribution (less than equal to 1°C) throughout the chamber. This level of precision ensures thorough sterilization and compliance with laboratory safety standards.

  • Yes, the Vertical Autoclave LVA-P11 offers adjustable sterilization and drying time ranges from 0 to 999 minutes, allowing users to customize the cycle based on load type and material sensitivity. This flexibility is especially useful in settings where a wide variety of items need sterilizing under different conditions.

  • Absolutely. The LVA-P11 is compatible with a wide voltage range of 110 to 240V, 50/60Hz, making it suitable for use in global laboratory and clinical environments. Its power consumption of 2.5 KW ensures efficient performance without overloading typical power systems, even in remote or resource-limited setups.

  • The Vertical Autoclave LVA-P11 is built entirely from high-grade stainless steel 304, offering corrosion resistance, structural strength, and hygiene. It includes casters with brakes for easy mobility and stability during use. The unit also incorporates a stainless-steel steam generator, contributing to its durability and performance during repeated sterilization cycles.
