| Heating Method | Direct Heating Air Jacket Type |
| Capacity | 185 L |
| Temperature Range | RT+3 to 60℃ |
| Temperature Uniformity | Less than or equal to ±0.25℃ |
| Temperature Fluctuation | Less than 0.05℃ |
| Temperature Recovery Time | Less than 4 mins |
| Service Temperature Range | 18 to 34℃ |
| CO2 Control Range | 0 to 20 %vol |
| CO2 Control Accuracy | ±0.1 %vol |
| CO2 Sensor Type | Infrared (IR) Sensor |
| Concentration Recovery Time | Less than 4 mins |
| Intake Pressure | 0.8 to 1.2bar |
| Humidification Method | Humidification Tray |
| Humidity Range | High Humidity Mode: greater than 90% RH, Low Humidity Mode: greater than 80% RH |
| Sterilization Method | Dry Heat Sterilization |
| Sterilization Temperature | 150℃ |
| Sterilization Duration | Less than 10h |
| Intake Filter | Less than 0.2 μm |
| Internal Circulation filter | High-Temperature Resistant HEPA Filter, No Need to Remove During Sterilization |
| Case Coating | Antibacterial Powder, Over 99% Antibacterial Efficiency |
| Inner Cavity Material | 304 Mirror-Finish Stainless Steel |
| Standard Number of Partitions | 3 |
| Maximum Power | 1200W |
| Power Supply | 220 to 240VAC 50/60Hz |
| Partition Dimension | 496 x 440 mm |
| Cavity Dimension (W x D x H) | 500 x 570 x 650 mm |
| Overall Dimension (W x D x H) | 685 x 700 x 870 mm |
| Gross Weight | 20Kg |
Our Air Jacketed CO2 Incubator is ideal for regenerative medicine facilities working with stem cells or tissue cultures, maintaining optimal atmospheric balance and sterility to support long-term viability and growth.
Download catalog for
Air Jacketed CO2 Incubator LAJI-B17 Catalog
Available Range :
Air Jacketed CO2 Incubator LAJI-C21 : 6 side direct heating Air Jacketed CO2 Incubator LAJI-C20 : 6 side heating Air Jacketed CO2 Incubator LAJI-C10 : Air-jacketed Air Jacketed CO2 Incubator LAJI-A10 : Air-jacketed, PID Control Air Jacketed CO2 Incubator LAJI-B16 : Direct Heating Air Jacket Type
Labtron Air-Jacketed CO2 Incubator is specialized to maintain optimal condition with chamber volume of 40 L to 570 L. Their dual-layer construction ensures stable internal temperature and protects against external fluctuations effectively. They are equipped with carbon dioxide monitoring system to measure accurate gas concentration levels. Their humidity control system prevents dehydration of cell cultures, promoting healthy growth environments consistently. Our Air-Jacketed CO2 Incubator culture sensitive cells and tissues for stem cell research and genetic engineering.
The Air Jacketed CO2 Incubator LAJI-B17 offers a compact 185-litre capacity, making it ideal for laboratories with limited space. Its efficient internal layout allows for optimal use of available volume without compromising performance. The unit supports consistent environmental conditions essential for sensitive samples. Despite its smaller footprint, it includes advanced features such as USB data export, alarms, and precise CO2 control. This makes it a reliable choice for small- to mid-scale research facilities.
The LAJI-B17 is specifically designed for applications in regenerative medicine, stem cell research, and tissue culture. It provides stable temperature, CO2 concentration, and humidity levels essential for cell viability and growth. The unit ensures contamination prevention through dry heat sterilization and HEPA filtration. Its advanced alarm system further protects sensitive cultures during long-term incubation. This makes it ideal for clinical, biopharmaceutical, and academic research environments.
The Air Jacketed CO2 Incubator LAJI-B17 uses six-sided heating and a dry heat sterilization system to maintain a contamination-free internal atmosphere. A high-temperature HEPA filter is installed and does not require removal during sterilization, ensuring continuous filtration. The chamber is fully sealed and made of mirror-finish stainless steel for easy cleaning and antimicrobial resistance. An anti-condensation door design and smart interface ensure uniform environmental control. These features together maintain sterility and performance throughout operation.
The incubator features a 7-inch touch screen with an intuitive interface for easy operation. Users can access operation logs, performance parameters, and error reports through USB export. A three-level management authority system restricts unauthorized access to system settings. Visual and audible alarms notify users immediately of temperature or CO? fluctuations. The interface supports real-time display of environmental conditions for effective monitoring. Data storage and retrieval are streamlined, supporting GLP/GMP compliance. These features make it user-friendly and suitable for regulated laboratory workflows.
The Air Jacketed CO2 Incubator LAJI-B17 uses a high-temperature resistant infrared (IR) sensor based on the NDIR (Non-Dispersive Infrared) principle. This sensor provides accurate and stable CO2 readings essential for sensitive cell cultures. It operates reliably without needing removal during sterilization, which minimizes user intervention. The sensor is installed inside the chamber for faster detection and environmental adjustment. With a service life of up to five years, it ensures long-term performance and minimal maintenance.
