| Test Range | 0 to 400 °C |
| Accuracy | ±0.1 °C |
| Receiving Chamber | 0 to 60 °C (0 °C achievable when AT < 15 °C) |
| Condenser Bath | Peltier cooling |
| Condenser Temperature Range | 0 to 60 °C (0 °C achievable when AT < 25 °C) |
| Heating System | Low mass/low voltage heater Unique heating optimization system for fully automatic initial heat settings and heating regulation |
| Safety Features | Monitor the whole test process automatically: Alarm and stop the test automatically if IBP cannot be detected in specified time. Alarm and stop the test automatically if the flow rate exceeds 15mL/min or no change for a long time during test. Alarm and stop heating if the temperature of condenser tube or receiving chamber is higher than 70℃. Built-in fire extinguisher, extinguish fire manually or automatically in case of fire (N2 supply required from lab) The system will turn off if expected dry point cannot be observed |
| IBP Detection | Infrared photoelectric detection |
| Dry Point Detection | Automatic dry point kit (optional) |
| Sample Volume Detection | Stepper motor with high-precision photoelectric sensor |
| Volume Range | 0 to 100 mL, 99 recovered volume points |
| Volume Accuracy | 0.1 mL |
| Pressure Correction | Automatic barometric correction |
| Data Storage | ≥ 5000 results |
| User Interface | 12 |
| I/O Ports | USB ×2, RS232 ×1, RJ-45 ×1 |
| Data Export | LIMS or Printer |
| Standards | ASTM D86, ISO 3405, IP 123, GB/T 6536 |
| Operating Conditions | 5℃ to 35℃ 20 to 90%RH No air flow |
| Power Consumption | 2000 W |
| Power Supply | AC 220 V ±10%, 50/60 Hz |
| Dimensions | 525×590×585 mm |
| Packaging Dimensions | 680 × 760 × 930 mm |
| Net weight | 90 kg |
| Gross weight | 100 kg |
Automated Atmospheric Distillation Tester is ideal in petroleum industry, chemical manufacturing, and quality control laboratories, providing accurate fractionation analysis for various liquid samples and applications.
Assembly Temperature Sensor
Dry Goods Set
PT100 Temperature Sensor
Locknut
O Molding Ring 1
O Molding Ring 2
Center Locator Upper
Center Locator Lower
Dry Sensor
Electric Furnace Assembly
Stone/Metal Plate for Furnace
Electric Furnace Heating Wire
Small Step Bushing
Electric Furnace Tube
Axial Flow Fan
Industrial Tablet
Dry Flask
Special Sealing Ring Measuring Cylinder Assembly
Switching Mode Power Supply
Switching Mode Power Supply RSP-2000-24
Stepper Motor
Stepper Motor Driver
Color Screen Stylus
Photoelectric Combination
Distilling Flask
Quartz Distillation Flask
Burette Cap
Deflector
Bracing Wire
USB Optical Mouse
Control Pulse
Semiconductor Cooling Engine PV-2 Series
Magnetic Circulation Pump
Solid State Relay
Solid-State Radiator
Heating Pad 32
Heating Pad 38
Heating Pad 50
Bullet Points
Download catalog for
Automated Atmospheric Distillation Tester LDT-A19 Catalog
Labtron Distillation Tester determine boiling point characteristics for analyzing purity and composition of substance. Their high-quality glass components ensure visibility while withstanding rigors of use. They utilize energy-efficient heating elements to minimize power consumption during lengthy processing. Their innovative design minimizes cross-contamination risks between different fractions, ensuring purity. Our Distillation Tester is suitable for oil and gas industry to assess crude oil fractions and in pharmaceuticals to check solvent purity.
The Automated Atmospheric Distillation Tester LDT-A19 uses an infrared sensor to spot the first drop of liquid, which marks the Initial Boiling Point (IBP). At the same time, it tracks the amount of liquid collected using a motor that moves the receiver with high accuracy. The final boiling point is worked out by checking how much liquid is collected and comparing it with the test settings. If needed, users can add a dry point kit to get more detail at the end of the distillation process.
Labtron's Automated Atmospheric Distillation Tester LDT-A19 uses a motor to move the receiver cylinder, which measures liquid volume in small steps of about 0.1?mL. This helps the system track the distillation process more accurately, especially at key points like 10%, 50%, and 90% recovery. The receiver moves automatically, so no manual changes are needed, which reduces user mistakes. This is very useful when testing fuel products that must meet strict rules.
Our Automated Atmospheric Distillation Tester LDT-A19 shows important values on the screen during the test like vapor temperature, heater temperature, receiver temperature, recovered volume, time, and distillation speed. These values help the user see how the sample is behaving and catch any problems early. Watching these values in real time lets users stay in control and make fast decisions if something goes wrong. This is helpful in both research labs and regular product testing.
The Automated Atmospheric Distillation Tester LDT-A19 shows a live curve on the screen that matches temperature with how much liquid has been collected. This helps users clearly see how the sample is performing during the test. If the curve changes too fast or looks strange, it might mean there's a problem with the sample or the setup. Seeing this right away helps users fix issues quickly and understand the sample better.
Our Automated Atmospheric Distillation Tester LDT-A19 gives warning messages and a graph that helps users understand what went wrong if the results don’t look right. Some reasons could be dirty glassware, wrong settings, or a bad sample. The system makes it easy to stop the test, clean parts, change the setup, or run the test again. This helps save time and keeps the lab running smoothly.
