System | Cascade |
Capacity | 338 L |
Temperature Range | -40℃ to -86℃ |
Ambient Temperature | 10℃ to 32℃ |
Refrigerant | HC (R290 and R170) |
Sensor | PTC |
Compressor | 2 |
Cooling Type | Direct Cooling |
Defrost | Manual |
Insulation | PURF |
Noise | 50 dB |
Compartment | 4 |
Inner door | 2 |
Racks | 12 (4 × 4) |
Boxes (2 Inch) | 192 |
Samples (2 ml) | 19200 |
Exterior material | Color Sprayed Steel |
Interior material | Stainless steel |
Remote Alarm Access | Yes |
RS 485 Access | Yes |
Alarms | High/low temperature Power failure Abnormal voltage Sensor error Door ajar Filter screen check Thermostat failure Low battery Condenser clean High ambient temperature 72 hr Power failure backup |
Current | 7.93A |
Power | 620 W |
Power consumption | 11.17 W h/24h |
Power Supply | 220V/50Hz |
Exterior Dimension | 854 × 1072 × 1907 mm |
Interior Dimension | 488 × 607 × 1140 mm |
Package Dimension | 935 × 1070 × 2128 mm |
Net Weight | 296 Kg |
Gross Weight | 306 Kg |
Download catalog for
-86 °C Ultra Low-Temperature Upright Freezer LUF-F10 Catalog
Available Range :
-86 °C Ultra Low-Temperature Upright Freezer LUF-F14 : Cascade -86 °C Ultra Low-Temperature Upright Freezer LUF-C10 : Dual System -86 °C Ultra Low Temperature Upright Freezer LUF-C13 : Sensor error, Built-in data logger USB failure , Main board communication error , Condenser cooling failure, Door ajar, Samples out of date, System failure -86 °C Ultra Low Temperature Upright Freezer LUF-C14 : Sensor error, Built-in data logger USB failure ,Main board communication error , System failure, Condenser cooling failure ,Door ajar, Samples out of date -86 °C Ultra Low Temperature Upright Freezer LUF-D20 : Sensor error, Main board communication error ,System failure, Condenser cooling failure, Door ajar, Samples out of date -86 °C Ultra Low Temperature Upright Freezer LUF-C11 : Sensor error, Main board communication error, Built-in data logger USB failure, Condenser cooling failure, Door ajar, Samples out of date, System failure -86 °C Ultra Low Temperature Upright Freezer LUF-D21 : Sensor error, System failure, Condenser cooling failure, Door ajarSimilar Products
