Benchtop conductivity meter LBCM-A11

Name: Benchtop conductivity meter LBCM-A11
Brand: Labtron
SKU: LBCM-A11
Rating: 4.7 (815 reviews)

Benchtop conductivity meter LBCM-A11 is easy to use, it comes with 1 - 3 point calibration system for automatic recognition of the known calibration standards. The LCD display helps to view the measurements and set parameters. The temperature calibration by manual method improves the accuracy of conductivity meter. The system of conductivity meter can set up to 6 parameters like number of calibration points, cell constant etc.

Request Quote

Conductivity measurement range	0 - 20.0, 200.0, 2000 µS / cm, 200.0 mS / cm
Conductivity accuracy	± 1 % F.S.
Conductivity resolution	0.01, 0.1, 1
Conductivity calibration solutions	10 µS / cm , 84 µS / cm, 1413 µS / cm, 12.88 mS / cm, 111.8 mS / cm
Conductivity calibration points	1 - 3 points
Temperature compensation range & mode	Manual or automatic, 0 to 100 °C , 32 to 212 °F
Temperature range	0 to 105 °C, 32 to 221 °F
Temperature accuracy	± 1°
Temperature resolution	0.1 °C
Temperature coefficient	0.0 to 10.0 % per °C
Cell constant	K= 0.1, 1, 10 or User-defined
Data hold function	Manual or automatic
Connector	6 - pin mini plug
Display	LCD (315 × 75 mm)
Power	DC 6 V / 400 mA power adapter, AC 220 V / 50Hz
Dimension (L × W × H)	210 × 205 × 75 mm
Packaging Dimension	340 x 210 x 300 mm
Weight	1.5 kg
Gross Weight	2.8 kg

Equipped with white backlit LCD display
1 - 3 point calibration with automatic recognition of calibration solution
Manual temperature compensation improves the measurement accuracy of meter
Automatic temperature compensation for accurate measured value over the entire range
Auto hold function freezes stable, final readings for better viewing and recording
Reset function automatically resumes all the settings to default mode
System menu allows setting the 6 parameters
Automatic power off helps to reduce battery power consumption
Help message as an operational guide for Quick access to the conductivity meter

The benchtop conductivity meter is used in water quality analysis, research, education, environmental monitoring, chemicals & liquids quality testing etc. for measuring conductivity.

Conductivity electrode
Temperature probe
DC 9 V power adapter

Conductivity electrode for pure water
Conductivity electrode for general liquids
Conductivity electrode for high conductivity
Conductivity standard solution 84 µS / cm, 1413 µS / cm, 12.88 mS / cm, 111.8 mS / cm

Download catalog for
Benchtop conductivity meter LBCM-A11 Catalog

Download manual for
Benchtop conductivity meter LBCM-A11 Manual

Available Range :

Benchtop conductivity meter LBCM-A11 : 0 - 20.0, 200.0, 2000 µS / cm, 200.0 mS / cm Benchtop Conductivity Meter LBCM-A13 : 0.000 μS/cm to 3000mS/cm Benchtop Conductivity Meter LBCM-B10 : 0.0000 to 400.0 mS/cm

Benchtop Conductivity Meter LBCM-C10

Conductivity Measuring Range : (0.00 to 20.00)μS/cm, (20.0 to 200.0)μS/cm(200 to 2000)μS/cm, (2.00 to 20.00)mS/cm(20.0 to 200.0)mS/cm(200 to 2000)mS/cm (K=10)TDS: 0 to 100 g/LSalinity: 0 to 100 pptResistivity: 0 to 100 MΩ·cm
Conductivity Resolution : 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm
Conductivity Accuracy : Electrode: ± 0.5% F S, Meter: ± 0.80% F S
Conductivity Temperature Compensation : 0 to 100℃, auto

Compare Remove

Benchtop Conductivity Meter LBCM-A14

Conductivity Mode : Conductivity measurement range0.01-20.0, 200.0, 2000 µS/cm, 20.00, 200.0 mS/cmConductivity accuracy±1% F.S.Conductivity resolution0.001, 0.01, 0.1, 1Conductivity calibration points1 to 3 pointsConductivity calibration solutions10 µS/cm , 84 µS/cm, 1413 µS/cm, 12.88 mS/cm, 111.8 mS/cm
TDS Mode : TDS measurement Range0 to 10.00, 100.0, 1000 ppm, 10.00, 100 ppt (Max. 200 ppt)TDS Accuracy± 1 % F.S.TDS Factor0.01 to 1.00 (default 0.5)TDS Calibration points3 points
Temperature Mode : Temperature range0 to 105°C, 32 to 221°FTemperature accuracy±1°CTemperature resolution0.1°C, 0.1°FTemperature calibration points1 pointTemperature Compensation Range and ModeManual or Automatic, 0 to 100°C , 32 to 212°FTemperature coefficient0.0 to 10.0 % per °C
Cell constant : K=0.1, 1, 10
