| Max Speed | 20000 rpm |
| Speed Accuracy | ± 10 rpm |
| Max RCF | 27994 × g |
| Capacity | 6 × 100 mL |
| Timing Range | 1 sec to 99 h 59 min 59 sec |
| Timing Increment | 1 sec |
| Display | LCD |
| Operation Mode | Touchscreen |
| Noise | Up to 60 dB (A) |
| ACC/DEC Rates | 40 rates |
| Programs | Up to 1000 |
| Power Consumption | 500 W |
| Dimension | 440 × 360 × 315 mm |
| Net Weight | 29 kg |
Automatic rotor recognition
Secure motorized lock
Durable and corrosion-resistant housing
Programmable multi-step centrifugation
Autoclavable rotors
Our High Speed Centrifuge LHS-C22 is used for rapid separation of biological samples such as cells, proteins, and nucleic acids. It is ideal for applications in clinical, research, and pharmaceutical laboratories.
Name | Max. Speed | Max. RCF | Capacity | Tube Size |
| Fixed Angle Rotor 01 | 20000 | 27994 × g | 12 × 1.5/2.2 mL | Ø11 × 42 mm |
| Fixed Angle Rotor 02 | 15000 | 18287 × g | 12 × 5 mL | Ø14 × 54 mm |
| Fixed Angle Rotor 03 | 16000 | 24814 × g | 24 × 1.5/2.2 mL | Ø11 × 42 mm |
| Fixed Angle Rotor 04 | 16000 | 24814 × g | 24 × 1.5/2.2 mL (Aerosol Tight) | Ø11 × 42 mm |
| Fixed Angle Rotor 05 | 13000 | 15625 × g | 12 × 10 mL | Ø16 × 86 mm |
| Fixed Angle Rotor 06 | 13000 | 15625 × g | 36 × 1.5/2.2 mL | Ø11 × 42 mm |
| Fixed Angle Rotor 07 | 12000 | 15712 × g | 6 × 50 mL Conical Bottom | Ø29 × 116 mm |
| Fixed Angle Rotor 08 | 12000 | 15712 × g | 6 × 50 mL Round Bottom | Ø29 × 111 mm |
| Fixed Angle Rotor 09 | 12000 | 15712 × g | 48 × 1.5/2.2 mL | Ø11 × 42 mm |
| Fixed Angle Rotor 10 | 10000 | 11045 × g | 4 × 100 mL | Ø38 × 123 mm |
| Fixed Angle Rotor 11 | 10000 | 11045 × g | 8 × 50 mL Conical Bottom | Ø29 × 116 mm |
| Fixed Angle Rotor 12 | 10000 | 11045 × g | 8 × 50 mL Round Bottom | Ø29 × 111 mm |
| Fixed Angle Rotor 13 | 10000 | 11045 × g | 12 × 15 mL | Ø17 × 112 mm |
| Fixed Angle Rotor 14 | 10000 | 11045 × g | 24 × 10 mL | Ø16 × 86 mm |
| Fixed Angle Rotor 15 | 16000 | 19004 × g | 6 × 10 mL | Ø16 × 86 mm |
| Fixed Angle Rotor 16 | 13000 | 14945 × g | 8 × 15 mL | Ø17 × 112 mm |
| Fixed Angle Rotor 17 | 13000 | 14945 × g | 6 × 30 mL | Ø25.5 × 100 mm |
| Fixed Angle Rotor 18 | 13000 | 14643 × g | 8 × 0.2 mL PCR Strip | — |
| Fixed Angle Rotor 19 | 8000 | 7720 × g | 6 × 100 mL | Ø38 × 123 mm |
| Microplate Rotor | 4000 | 1538 × g | 2 × 2 × 48 Well Plate | 128 × 48 × 60 mm |
Download catalog for
High Speed Centrifuge LHS-C22 Catalog
Labtron High Speed Centrifuge is specialized to separate components of mixture based on density through rapid rotation. They operate by spinning samples at high speed of 12000rpm to 21000rpm generating significant centrifugal forces. Their tubes are designed to withstand elevated g-forces without breaking or leaking. They incorporate advanced cooling systems to maintain optimal temperatures during centrifugation processes. Our High Speed Centrifuge is essential in medical laboratories for blood separation and biopharmaceutical companies for product purification.
Labtron’s High Speed Centrifuge LHS-C22 offers a maximum speed of 20000 rpm and a maximum relative centrifugal force (RCF) of 27994 × g. This high-performance capability makes it ideal for applications that require rapid separation of small particles, such as nucleic acids, proteins, and subcellular components. Its precision and high rotational force ensure accurate and consistent results across a wide range of laboratory procedures.
The High Speed Centrifuge LHS-C22 is designed for long-term use in demanding laboratory environments. It features a 304-grade stainless steel chamber that is coated with Teflon, which provides exceptional resistance to corrosion and simplifies cleaning. This combination of materials ensures that it can withstand frequent usage, exposure to chemical reagents, and rigorous decontamination protocols without degrading its structural integrity.
Our High Speed Centrifuge LHS-C22 incorporates several safety measures to protect users and ensure secure operation. It includes an automatic rotor recognition system, which prevents the use of incompatible rotors, and a motorized safety lock that keeps the lid securely closed during runs. Additionally, it features a password protection system to restrict unauthorized access, an emergency door lock release for safe shutdown, and a calibration port built into the door for performance validation and maintenance.
Yes, the High Speed Centrifuge LHS-C22 is highly programmable and user-friendly. It features a touchscreen LCD interface that allows users to easily set and monitor parameters. It supports up to 1000 user-defined programs and enables multi-step centrifugation, allowing for complex workflows such as gradient separations or varying speed cycles. This makes it ideal for labs conducting repeated or highly customized procedures.
