| Temperature Range | -25°C to 90°C |
| Temperature Control | ±0.05°C |
| Expansion Tank Volume | 10L |
| Fluid Volume | 4L Internal Circulation |
| Flow Control | 10 to 25L/min |
| Cooling Water flow | 1.2m³/H at 20°C |
| Refrigerant | R448A |
| Cooling Capacity | 2Kw at -15°C |
| Dimension | 950mm x 380mm x 1060mm |
| Net Weight | 170 kg |
| Gross Weight | 270 kg |
Energy-Saving Design
Temperature Stabilization Feature
Built-in Diagnostic System
Rapid Heat Dissipation
High Flow Rate
Our Recirculating Chiller is employed in HVAC systems to maintain proper fluid cooling for climate control, providing effective heat transfer and stable operation for industrial heating, ventilation, and air conditioning systems.
Download catalog for
Recirculating Chiller LRC-C10 Catalog
Available Range :
Recirculating Chiller LRC-F10 : -100°C to 90°C Recirculating Chiller LRC-A12 : -20 ℃ to RT Recirculating Chiller LRC-L10 : -20°C to RT Recirculating Chiller LRC-A11 : -20℃ to RT Recirculating Chiller LRC-C10 : -25°C to 90°C Recirculating Chiller LRC-D10 : -45°C to 90°C Recirculating Chiller LRC-E10 : -80°C to 90°C Recirculating Chiller LRC-B10 : 5°C to 90°C Recirculating Chiller LRC-A10 : 5˚C to 40˚C Recirculating Chillers LRC-L11 : –20 to 25°C Recirculating Chillers LRC-L12 : –30 to 5°C
Labtron Recirculating Chiller provide cooling of fluids from -5℃ to 40℃ by circulating them through system to remove heat. They include evaporators to absorb thermal energy from liquid ensuring temperature control. Their expansion valves control flow of refrigerant and regulate freezing capacity of system. They feature filtration system to remove particulates and impurities from solution. Our Recirculating Chiller is applicable for automotive testing, electronics, medical and pharmaceutical equipment.








Labtron recirculating chillers are commonly used in laboratory experiments, cooling temperature-sensitive equipment, lasers, reactors, and other industrial applications requiring precise and efficient cooling. These chillers are ideal for maintaining stable and consistent temperature conditions, making them crucial for experiments, processes, and industries where accurate thermal control is vital.
Our recirculating chillers are engineered with energy-efficient components, such as variable-speed pumps and advanced heat exchange systems, which reduce power consumption while maintaining high cooling performance. This results in lower operating costs and makes our chillers an environmentally friendly choice, contributing to both cost savings and sustainability in operations.
Yes, Labtron offers a range of recirculating chiller models capable of handling both small and large volume cooling applications. Our chillers are designed to efficiently manage substantial heat dissipation needs, making them ideal for industrial processes, large-scale manufacturing, or any application requiring high cooling capacity. Depending on the model, they can maintain precise temperature control even in high-demand situations.
Yes, our recirculating chillers are engineered to operate efficiently in a range of ambient temperatures, including high-temperature environments. However, it’s important to ensure that the chiller’s specifications, such as cooling capacity and maximum operating temperature, align with specific workspace conditions. Some of our models are designed with high-temperature-resistant components to ensure reliable performance even in extreme conditions.
Labtron recirculating chillers offer several advantages over traditional cooling systems, such as cooling towers or air-cooled units. These include precise temperature control, greater energy efficiency, reduced operational costs, and easier maintenance. Unlike traditional systems, recirculating chillers reuse coolant, which lowers water consumption and helps to maintain stable, consistent cooling conditions. This not only enhances the performance and lifespan of sensitive equipment but also reduces overall operational and environmental costs.
Yes, our recirculating chillers come equipped with a range of safety features, such as overheat protection, low coolant level alarms, and automatic shut-off systems. These features help prevent damage to both the chiller and the connected equipment, ensuring safe operation.
