Vertical Autoclave LVA-D10

Vertical Autoclave LVA-D10

Vertical Autoclave LVA-D10 is a class N-type top-loading vertical pressure steam sterilizer, with hand wheel type, quick to open door structure. It offers a chamber capacity of 35 L, working sterilization temperature and pressure of 134°C and 0.22 MPa respectively. Designed with four wheels (castors) at the base for easy movement of the unit. The standard 02 pcs of stainless steel baskets to keep the sterilization material load. The 304-grade stainless steel with superior corrosion resistance property is used as a construction material for the autoclave. It works on electric heating or direct heating by immersing copper tubes of heating elements. It is possible to customize autoclave with an optional drying system, according to the request.

Available Range :

Capacity : 35 L Capacity : 100 L Capacity : 50 L Capacity : 36 L Capacity : 50 L Capacity : 75 L
Capacity 35 L
Chamber Volume 318×450 mm
Working Sterilization Temperature 134°C
Working Sterilization Pressure 0.22 MPa
Time Range 0 to 99 mins
Maximum Working Pressure 0.23 MPa
Sterilization Temperature Range 105 to 134°C
Heat Average ≤ ± 1°C
Power Consumption 2.5 kW
Power supply AC 220 V, 50 Hz
Overall Dimension 480×450×1010 mm
Packing Dimension 570×550×1150 mm
Net weight 56 kg
Gross weight 72 kg
  • Stainless steel body structure, with hand wheel type structure to quickly open the door
  • Door safety lock system
  • Digital LCD display with touch keypad
  • Auto discharge the cool air, and steam discharging automatically after sterilization
  • Automatic shutdown with beep sound as sterilization completes
  • Class N-type Autoclave, Optional drying system, can be equipped according to the request
  • Two stainless steel sterilizing baskets as a standard accessory
  • Auto power cut in case of water shortage
  • Self-inflating type seal is used to prevent leakage
  • Over-temperature & over pressure auto-protection
  • Easy to operate, safe, and reliable

Vertical autoclave used in the pharmaceutical industry, medicine and health care industry, Biotechnology, Microbiology for effective sterilization of glassware’s, biological materials, culture media, and others.

Accessory no. Name Material Quantity
1 Basket Stainless steel 02 pcs

Drying System
