Bending Beam Rheometer LBMR-A10 is equipped with a 0 to 10 mm displacement sensor for accurate deformation monitoring during low-temperature testing. The adjustable-speed magnetic stirrer ensures a uniform bath temperature. It features overload protection with alarms ensuring safe operation and easy troubleshooting. Our Bending Beam Rheometer applies a constant load to accurately assess asphalt binder stiffness and resistance at low temperature.
| Displacement Sensor Range | 0 to 10 mm |
| Stirrer Speed | 25 rpm |
| Displacement Sensor Resolution | 5 μm |
| Pressure Sensor Range | 0 to 4900mN |
| Pressure Sensor Resolution | 2 mN |
| Temperature Sensor Range | -50℃ to room temperature |
| Temperature Sensor Accuracy | ± 0.1℃ |
| Liquid Bath Temperature Range | -40℃ to room temperature |
| Temperature Control Accuracy | ±0.1℃ |
| Liquid Bath Capacity | 5L |
| Top Radius Of Sample Support | 3 ± 0.3 mm |
| Loading Shaft Radius | 6.3 ± 1.3 mm spherical contact point |
| Creep Stiffness Range | 20 to 1000MPa |
| Data Output | USB port |
| Power Box | AC220V 1800 W |
| Chiller Power | AC220V 3000 W |
| Power Consumption | 1000 W |
| Power Supply | AC220V |
| Dimensions | 610×610×620 mm |
| Weight | 80 kg |
Industrial-grade control interface
Rapid hybrid cooling system
Vibration-free chiller design
Customizable test duration setting
Reliable overload protection system
Bending Beam Rheometer LBMR-A10 evaluates asphalt binder stiffness under low-temperature loading. It is applied in road construction, asphalt research labs, and pavement quality control facilities.
