The Analytical Ferrospectrometer LALF-B10 is used for analyzing iron particles and their separation in samples to facilitate better research on petroleum oil. Its sample preparation requires minimal amounts of chemicals, and it does not interfere with the composition of the sample. It provides a ferrogram library to determine the wear fault locations accurately and causes in the sample. Additionally, it has an adjustable speed, which improves the success rate of ferrography of the sample. Our Analytical Ferrospectrometer has wide applications like the railway system, steel industry, electric Power Industry, and naval defense.
| Magnetic Field Flux Density | Up to 1.5T |
| Maximum magnetic Field Gradient | More than 0.5 T/mm |
| Oil Sample Flow Rate | 2-3 ml/min |
| Oil Delivery Pipe Size | Outer Diameter- 2.6 mm, Inner Diameter- 1.8 mm |
| Ferrograph Inclination | 1˚ - 5˚ |
| Ferrographic Substrate Size | 60 × 24 × 0.17 mm |
| Optical System | Infinitely distant system |
| Eyepiece | EW10×/22, mirror length Φ30 |
| Flat field achromatic Objective at infinity range | 10×/0.25/∞/-(BF/DF) WD 10.0mm |
| Viewing head | Hinged triocular viewing head, 30° tilt, pupil distance 48-75mm |
| Maximum specimen height | 50 mm |
| Reflection illumination | 24V/100W halogen lamp (pre-centering) with adjustable brightness Kohler lighting system, aspherical light collector Blue, green and yellow filters and frosted glass |
| Transmission lighting system | Pendulum condenser NA0.9/0.25 |
| Focusing system | Coarse-motion coaxial focusing, fine tuning cell value 1μm, coarse-motion elastic adjustment, with limiting device |
| Convertor | Five-hole Convertor |
| Operating temperature | 18-35°C |
| Weight | 9.6 Kg. |
| Power supply | AC 220V ±10%, 50Hz |
Detection of microscopic properties
Less solvent requirement
Highly accurate analysis
Compact and convenient design
User-friendly application
The Analytical Ferrospectrometer LALF-B10 is used for analyzing iron particles and their separation in samples to facilitate better research on petroleum oil. Our Analytical Ferrospectrometer has wide applications like the railway system, the steel industry, the electric Power Industry, and naval defense.
